DVB-S Receiver with SCART, SD and MPEG-2 Functions

DVB-S Receiver with SCART, SD and MPEG-2 Functions

Get Latest Price

Payment Type:: T/T, Western Union, L/C or PayPal

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, Western Union, L/C or PayPal

Product Description

With Biss/CW

Three sets tooling for customer choice (A/B/C)

Without PVR function

Without media player and photo viewer function

Two directional rotatable head

Easy to assemble and disassemble

Type: SD, MPEG-2, DVB-S receiver

Solution: national chipset, 6101D+AV2026

Software features:

PAL/NTSC: automatic PAL/NTSC conversion, PAL/NTSC video outputsupport
Channel number: 3000 channels TV and radio programmable
Favorites: 6 different favorite groups selection
OSD language: English, Russian, Turkish, Persian, Arabic,Portuguese and French
Channel search: channel search in automatic, manual and networksearch
Software upgrade: through RS232 port, over the air softwareupgrade support
Save channel: automatic save for last channel

Main chipsets:

CPU frequency: 133MHz
Flash memory: 1pc 8Mbit/1MByte
SDRAM memory: 1pc 8 x 16Mbit/8Mbyte
Demodulator IC: building in main chipset
DVB-S channel decoder
Demode standard: DVB-S/MPEG-2 compliant (ETSI EN 302 307)
Demodulation: QPSK
FFT size: 2 and 8K
Code rate: 1/2, 2/3, 3/4, 5/6 and 7/8
Demultiplexer: MPEG2 ISO and IEC 13818-1
Input bit rate: maximum 60Mbit/s
Audio decoding: MPEG1/2, ISO, IEC 13818-3 layer 1 and 2
Sound mode: left, right and stereo
Sampling frequency: 32KHz, 44.1KHz and 48KHz
Input voltage: 175 to 250V AC, 50/60Hz
Consumption: maximum 8W

Environmental:

Temperature: 0 to 40°C
Humidity: d95%

PAL/NTSC: automatic PAL/NTSC conversion, PAL/NTSC video outputsupport

Channel number: 3000 channels TV and radio programmable

Favorites: 6 different favorite groups selection

OSD language: English, Russian, Turkish, Persian, Arabic,Portuguese and French

Channel search: channel search in automatic, manual and networksearch

Software upgrade: through RS232 port, over the air softwareupgrade support

Save channel: automatic save for last channel

CPU frequency: 133MHz

Flash memory: 1pc 8Mbit/1MByte

SDRAM memory: 1pc 8 x 16Mbit/8Mbyte

Demodulator IC: building in main chipset

DVB-S channel decoder

Demode standard: DVB-S/MPEG-2 compliant (ETSI EN 302 307)

Demodulation: QPSK

FFT size: 2 and 8K

Code rate: 1/2, 2/3, 3/4, 5/6 and 7/8

Demultiplexer: MPEG2 ISO and IEC 13818-1

Input bit rate: maximum 60Mbit/s

Audio decoding: MPEG1/2, ISO, IEC 13818-3 layer 1 and 2

Sound mode: left, right and stereo

Sampling frequency: 32KHz, 44.1KHz and 48KHz

Input voltage: 175 to 250V AC, 50/60Hz

Consumption: maximum 8W

Temperature: 0 to 40°C

Humidity: d95%
