5 Slots Armature 24V DC Electric Vehicle Motor with Metal End Cap, for Cars
  • 5 Slots Armature 24V DC Electric Vehicle Motor with Metal End Cap, for Cars
5 Slots Armature 24V DC Electric Vehicle Motor with Metal End Cap, for Cars

5 Slots Armature 24V DC Electric Vehicle Motor with Metal End Cap, for Cars

Get Latest Price
Payment Type:
T/T, L/C, Western Union, Cash, PayPal or MoneyGram
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: T/T, L/C, Western Union, Cash, PayPal or MoneyGram
Product Description
Product Description
  • Features:
    • Metal end cap
    • Sintered bronze bearing
    • Leaf brush system
    • 5 slots armature
  • Dimensions:
    • Diameter: 27.7mm
    • Length: 37.8mm
    • Shaft diameter: 2.3mm
  • Performance:
    • Voltage:
      • Operating range: 6.0-24.0V
      • Nominal voltage: 24V
    • No Load:
      • Speed: 11,000rpm
      • Current: 0.15A
    • At maximum efficiency:
      • Speed: 9,034rpm
      • Current: 0.69A
      • Torque: 10.7mNm/109g.cm
      • Output: 10.12W
      • Stall torque: 59.8mNm/610g.cm
      • Stall current: 3.16A
    • Direction of rotation: CW/CCW
    • Note: all of the data could be customized according to your demand
  • Typical application:
    • Printer/copy machine
    • Automatic cruise control
    • Drill/screwdriver
    • Vacuum cleaner
  • Metal end cap
  • Sintered bronze bearing
  • Leaf brush system
  • 5 slots armature
  • Diameter: 27.7mm
  • Length: 37.8mm
  • Shaft diameter: 2.3mm
  • Voltage:
    • Operating range: 6.0-24.0V
    • Nominal voltage: 24V
  • No Load:
    • Speed: 11,000rpm
    • Current: 0.15A
  • At maximum efficiency:
    • Speed: 9,034rpm
    • Current: 0.69A
    • Torque: 10.7mNm/109g.cm
    • Output: 10.12W
    • Stall torque: 59.8mNm/610g.cm
    • Stall current: 3.16A
  • Direction of rotation: CW/CCW
  • Note: all of the data could be customized according to your demand
  • Operating range: 6.0-24.0V
  • Nominal voltage: 24V
  • Speed: 11,000rpm
  • Current: 0.15A
  • Speed: 9,034rpm
  • Current: 0.69A
  • Torque: 10.7mNm/109g.cm
  • Output: 10.12W
  • Stall torque: 59.8mNm/610g.cm
  • Stall current: 3.16A
  • Printer/copy machine
  • Automatic cruise control
  • Drill/screwdriver
  • Vacuum cleaner
