24V DC Gear Motor for Dispenser/Robots/Paper Towers, with 37mm Diameter Gearbox and Offset 6mm Shaft

Get Latest Price

Payment Type:: T/T or L/C

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T or L/C

Product Description

Dimensions:

Gearbox diameter: 37mm

Total lengths: 55.6 to 67mm

Length varies with reduction ratio

Shaft diameter: offset 6mm with customized length and D-shapedsize and length

Gear ratio: 1/6.5, 1/10, 1/15, 1/19.5 1/20, 1/24, 1/28,1/30,1/35,1/40, 1/50,1/56,1/58.5,1/60,1/70,1/83,1/90,1/106,1/150,1/180,1/210,1/270,1/168,1/280,1/360,1/432,1/450,1/540,1/630,1/810/,1/1084

Technical performance data:

Nominal voltage: 24V

No load speed: 85rpm

No load current: 1A (maximum)

Rated loading speed: 72.5rpm

Rated loading current: 2.6A

Rated loading torque: 5kg/cm

Customization options:

OEM and customized orders are welcome

Compliant with the RoHS Directive

Ball bearing in output side

EMI suppression

Low-cogging design

High degree of protection

Small mechanical time constant

Resists intense vibrations

Zero axial gap

Low noise design

Fast response (small Tm)

High torque at a low speed

PTC protection

Penolic resin base commutator

Epoxy coating armature

Lightweight and long lifespan

Diameters: 6 to 52mm

DC voltage range: 1.5 to 42V

AC rectify: 100V, 110V, 220V, 230V, 240V and more

Speed range: 1 to 30,000rpm

Stall torque: 5g.cm to 30kg.cm

Applications: home appliances, power tools, toys and models,precision instrument, office equipment, personal care product,automotive, audio/visual equipment and more
