1.2V Micro DC Motor, 24 x 18.3 x 30.5mm Housing, Ideal for Toys, Power Fans, Scissors, Door Locks
  • 1.2V Micro DC Motor, 24 x 18.3 x 30.5mm Housing, Ideal for Toys, Power Fans, Scissors, Door Locks
1.2V Micro DC Motor, 24 x 18.3 x 30.5mm Housing, Ideal for Toys, Power Fans, Scissors, Door Locks

1.2V Micro DC Motor, 24 x 18.3 x 30.5mm Housing, Ideal for Toys, Power Fans, Scissors, Door Locks

Get Latest Price
Payment Type:
T/T or L/C
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: T/T or L/C
Product Description
Product Description
  • Specifications:
    • Motor housing (D x flat x L): 24 x 18.3 x 30.5mm (material:SECD)
    • Shaft (diameter): 2.0mm carbon steel (nickel coating)
    • Way of commutation: carbon brush
    • Structure: 2-pole stator and 3-slot armature
    • Rotation: CW/CCW and reversible
    • Male terminals
    • Options: extended shaft on the end cap side, EMI/EMCsuppression
  • Technical performance data:
    • Rated voltage: 1.2V DC
    • At no load:
      • Speed: 8,670rpm
      • Current: 0.73A
    • Efficiency (maximum):
      • Speed: 6,560rpm
      • Current: 2.24A
      • Torque: 17.7g/cm
    • At stall:
      • Current: 8.43A (maximum)
      • Torque: 98g/cm
    • Customized data requirements are welcomed for our engineer'sevaluation
  • Suitable for toys, power fans, scissors and door locks
  • Motor housing (D x flat x L): 24 x 18.3 x 30.5mm (material:SECD)
  • Shaft (diameter): 2.0mm carbon steel (nickel coating)
  • Way of commutation: carbon brush
  • Structure: 2-pole stator and 3-slot armature
  • Rotation: CW/CCW and reversible
  • Male terminals
  • Options: extended shaft on the end cap side, EMI/EMCsuppression
  • Rated voltage: 1.2V DC
  • At no load:
    • Speed: 8,670rpm
    • Current: 0.73A
  • Efficiency (maximum):
    • Speed: 6,560rpm
    • Current: 2.24A
    • Torque: 17.7g/cm
  • At stall:
    • Current: 8.43A (maximum)
    • Torque: 98g/cm
  • Customized data requirements are welcomed for our engineer'sevaluation
  • Speed: 8,670rpm
  • Current: 0.73A
  • Speed: 6,560rpm
  • Current: 2.24A
  • Torque: 17.7g/cm
  • Current: 8.43A (maximum)
  • Torque: 98g/cm
