1.9V DC Motor, 24.4 x 12.5mm Housing, Ideal for Game Controllers, CD/DVD Players, RC Toys and Models
  • 1.9V DC Motor, 24.4 x 12.5mm Housing, Ideal for Game Controllers, CD/DVD Players, RC Toys and Models
1.9V DC Motor, 24.4 x 12.5mm Housing, Ideal for Game Controllers, CD/DVD Players, RC Toys and Models

1.9V DC Motor, 24.4 x 12.5mm Housing, Ideal for Game Controllers, CD/DVD Players, RC Toys and Models

Get Latest Price
Payment Type:
T/T or L/C at Sight
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: T/T or L/C at Sight
Product Description
Product Description
  • Specifications:
    • Motor housing size: 24.4 x 12.5mm
    • Material: SECD
    • Shaft: 2.0mm carbon steel (nickel coating)
    • Way of commutation: metal brush
    • Structure: 2 poles stator and 3 slots armature
    • Rotation: CW/CCW
    • Options: EMI/EMC suppression
  • Technical performance data:
    • Rated voltage: 1.9V DC
    • At no load:
      • Speed: 3000 ± 10% rpm
      • Current: 30 mA max
    • At 4g.cm load:
      • Speed:2200 ± 10% rpm
      • Current: 110mA
    • At stall:
      • Current: 400mA (maximum)
      • Torque: 13g.cm
    • Customized data requirements are welcome
    • Suitable for game controllers, CD/DVD players and RC toys andmodels
  • Motor housing size: 24.4 x 12.5mm
  • Material: SECD
  • Shaft: 2.0mm carbon steel (nickel coating)
  • Way of commutation: metal brush
  • Structure: 2 poles stator and 3 slots armature
  • Rotation: CW/CCW
  • Options: EMI/EMC suppression
  • Rated voltage: 1.9V DC
  • At no load:
    • Speed: 3000 ± 10% rpm
    • Current: 30 mA max
  • At 4g.cm load:
    • Speed:2200 ± 10% rpm
    • Current: 110mA
  • At stall:
    • Current: 400mA (maximum)
    • Torque: 13g.cm
  • Customized data requirements are welcome
  • Suitable for game controllers, CD/DVD players and RC toys andmodels
  • Speed: 3000 ± 10% rpm
  • Current: 30 mA max
  • Speed:2200 ± 10% rpm
  • Current: 110mA
  • Current: 400mA (maximum)
  • Torque: 13g.cm
