Product Description

Features:

NdFeB magnet
Precious metal brush
Stainless steel shaft

Technical data:

Nominal voltage: 4.8V
No load:
- Speed: 42,995rpm
- Current: 0.07A
At maximum efficiency:
- Speed: 34,777rpm
- Current: 0.32A
- Torque: 0.13mN.m or 1.4g.cm
- Output: 0.51W
Stall:
- Torque: 0.5mN.m or 5.1g.cm
- Current: 1.4A

Typical applications:

Note book PC
Optical disk drive
Epilator

Our main products:

Our main products: Motor, auto dc motor,dc electric motor, Gear Motor, DC Motor, Brush DC motor, Spur Gear motor, Micro Motor, Vibration motor and more
Products size range: diameter:6-52mm
DC voltage range:1.5V-42V.
AC rectify: 100V, 110V, 220V, 230V, 240V and more
Speed range:1RPM-30,000RPM
Stall torque: 5g.cm-30kg.cm
Applications: Home appliance, power tools, toys & model, precision Instrument, office equipment, personal care product, automotives, audio&visual equipment and more

NdFeB magnet

Precious metal brush

Stainless steel shaft

Nominal voltage: 4.8V

No load:

Speed: 42,995rpm
Current: 0.07A

At maximum efficiency:

Speed: 34,777rpm
Current: 0.32A
Torque: 0.13mN.m or 1.4g.cm
Output: 0.51W

Stall:

Torque: 0.5mN.m or 5.1g.cm
Current: 1.4A

Speed: 42,995rpm

Current: 0.07A

Speed: 34,777rpm

Current: 0.32A

Torque: 0.13mN.m or 1.4g.cm

Output: 0.51W

Torque: 0.5mN.m or 5.1g.cm

Current: 1.4A

Note book PC

Optical disk drive

Epilator

Our main products: Motor, auto dc motor,dc electric motor, Gear Motor, DC Motor, Brush DC motor, Spur Gear motor, Micro Motor, Vibration motor and more

Products size range: diameter:6-52mm

DC voltage range:1.5V-42V.

AC rectify: 100V, 110V, 220V, 230V, 240V and more

Speed range:1RPM-30,000RPM

Stall torque: 5g.cm-30kg.cm

Applications: Home appliance, power tools, toys & model, precision Instrument, office equipment, personal care product, automotives, audio&visual equipment and more
