Best price 24V DC motor with reduction gearbox for air pump
  • Best price 24V DC motor with reduction gearbox for air pump
Best price 24V DC motor with reduction gearbox for air pump

Best price 24V DC motor with reduction gearbox for air pump

Get Latest Price
Payment Type:
T/T or L/C at Sight
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: T/T or L/C at Sight
Product Description
Product Description
  • Specifications:
    • Motor housing size (D x L): 45mm x 66mm
    • Housing material: SECD
    • Shaft: 5.0mm carbon steel (nickel-coated)
    • Way of commutation: carbon leaf brush system
    • Ball bearing on the driving sides is available
    • Structure: 2 poles stator and 3 slots armature
    • Insulation: class F magnet wire
    • Rotation: CW/CCW and reversible
    • Suitable for cordless power tools, oil pumps and fitness apparatus
  • Performance:
    • Nominal voltage: 24V DC
    • At no load:
      • Speed: 5,000rpm
      • Current: 0.19A
    • At maximum efficiency:
      • Speed: 4470rpm
      • Current: 0.79A
      • Torque: 34.1mNm/348g.cm
      • Output: 15.48W
    • At stall:
      • Current: 9.72A
      • Torque: 223.5mNm/2280kg.cm
    • Options: shaft length, technical data like voltage, speed, torque, EMI and EMC suppression.
  • Packing(for your reference):
    • Quantity: 42 pieces
    • Gross weight: 15.3kg
    • Dimensions: 41.0 x 27.5 x 18.0cm
  • Customization options:
    • OEM and customization are accepted
    • Compliant with the RoHS Directive
    • Ball bearing in output side
    • EMI suppression
    • Low-cogging design
    • High degree of protection
    • Small mechanical time constant
    • Resist intense vibrations
    • Zero axial gap
    • Low noise design
    • Fast response (small Tm)
    • High torque at a low speed
    • PTC protection
    • Phenolic resin base commentator
    • Epoxy coating armature
    • Lightweight and long lifespan
  • We assure our products in high quality, economical price and all-round services after sale
  • If you are into our  products, please don't hesitate to inquiry
