UTP Cat5e Cable, from Reliable LAN Cable Manufacturer with PVC, LSZH, LDPE and Rip Wire JacketNew

UTP Cat5e Cable, from Reliable LAN Cable Manufacturer with PVC, LSZH, LDPE and Rip Wire JacketNew

Get Latest Price

Payment Type:: T/T or Western Union, 30% in Advance and 70% befor

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T or Western Union, 30% in Advance and 70% befor

Product Description

Specifications:

4 pairs 4 x 2 x 0.45mm pure copper or CCA or CCS, PE insulation 1.02mm + rip code + PVC jacket, light grey or white
Material: solid bare copper
Number of pairs: 4
Conductor diameter: 0.50 ±0.003mm
Insulation materials: HDPE and FRPE
Diameter: 0.924 ±0.005mm
Average thickness: 0.212mm
Minimum point thickness: 0.2095mm
Colors: red, black, green, yellow, pink, blue, white, gray, purple all colors (optional)
Signal transmission smooth
Past fluke test: 80m
Working distance up to 120m
Your company name and logos printing from free
Main products: Cat5e, 6, 6a
Conductor: you can choose conductor as bare copper, pure copper or CCA
Structure: solid or stranded (optional)
Jacket: PVC or LSZH (optional)
Standard: 24, 26 and 28AWG (optional)
Performance: UTP, FTP STP, SFTP (optional)
Size: 100, 305 or 500m per roll
Industrial standards: YD/T1019-2001, (USA) ANSI/TIA/EIA-568-B, (Worldwide) IEC 11801/71156
Conductor: solid and stranded copper wire
Jacket: PVC, LSZH, LDPE, rip wire
Color: optional
Length: 1,000ft per carton
Rating temperature: 75°C
UTP: small diameter save space, lightweight, flexible, easy cabling, low-price
FTP/STP: reduce or eliminate a next, independence and flexible, more strong flame retardant
Suitable for structure and wiring
Warm tip: please contact supplier by phone before you do any payment, check the right foreign exchange corporate account carefully, do not pay to any private bank account without any guarantee from real supplier

Packing:

100m: PE protective layer, 5 roll per carton box
305m: one roll in one carton box, two carton boxes in one master carton
500m: wooden roll package, carton box as outer package

4 pairs 4 x 2 x 0.45mm pure copper or CCA or CCS, PE insulation 1.02mm + rip code + PVC jacket, light grey or white

Material: solid bare copper

Number of pairs: 4

Conductor diameter: 0.50 ±0.003mm

Insulation materials: HDPE and FRPE

Diameter: 0.924 ±0.005mm

Average thickness: 0.212mm

Minimum point thickness: 0.2095mm

Colors: red, black, green, yellow, pink, blue, white, gray, purple all colors (optional)

Signal transmission smooth

Past fluke test: 80m

Working distance up to 120m

Your company name and logos printing from free

Main products: Cat5e, 6, 6a

Conductor: you can choose conductor as bare copper, pure copper or CCA

Structure: solid or stranded (optional)

Jacket: PVC or LSZH (optional)

Standard: 24, 26 and 28AWG (optional)

Performance: UTP, FTP STP, SFTP (optional)

Size: 100, 305 or 500m per roll

Industrial standards: YD/T1019-2001, (USA) ANSI/TIA/EIA-568-B, (Worldwide) IEC 11801/71156

Conductor: solid and stranded copper wire

Jacket: PVC, LSZH, LDPE, rip wire

Color: optional

Length: 1,000ft per carton

Rating temperature: 75°C

UTP: small diameter save space, lightweight, flexible, easy cabling, low-price

FTP/STP: reduce or eliminate a next, independence and flexible, more strong flame retardant

Suitable for structure and wiring

Warm tip: please contact supplier by phone before you do any payment, check the right foreign exchange corporate account carefully, do not pay to any private bank account without any guarantee from real supplier

100m: PE protective layer, 5 roll per carton box

305m: one roll in one carton box, two carton boxes in one master carton

500m: wooden roll package, carton box as outer package
