Product Description

Performance parameters:

Light source type: Visual lasing diode
The wave length is 650mm
Trigger mode: Manual (can be switched off after the on/off button is pressed for several seconds)
Scanning pattern: Single-line scanning
Scanning speed: 100±2 times/s
Resolution: ≥4mil
Printing contrast ratio: The lowest reflectivity difference is 30％
Bit error rate: 1/50 million
Charging input voltage: 5V DC±0.25V
Power: 100mW (work): 500mW (momentary maximum)
Current: 20mA (work): 100mA (momentary maximum)
Standby current: ＜20uA
Light intensity: 3,000-12,000Lux
Depth of field: 5-630mm
Scanning angle: ±60°±65°±42° (Left and right, front and back, rotation)
Decoding capacity: UPC/EAN/JAN, UPC/EAN with supplemental, UCC/EAN 128, code 39, MSI, code11, Code 39 Full ASCII, code 39 TriOptic, code 128, Code 128Full ASCII, codabar, code93, Discrete2of5, IATA, RSS variants, codabar, Chinese2of5, International general dimensional barcodes, e.g. Inteleaved2/5, Interleaved2of5 and China postal service code
Promotion pattern: Buzzer and LED indicator
Weight: 200g
Charging interface type: RJ-45 crystal head, one meter long (equipped with 5V charger; the battery is being charged when the red light is on and fully charged when the green light is on).
Hull materials: ABS+PC
Temperatures: 0 to 50℃ (Work), -40 to 60℃ (storage)
Setting mode: Manual (scanning and setting barcodes according to the sequence)
Laser safety class: EN60825-1, class 1, national level-I laser safety standard
EMC: EN55022, EN55024
Electrical safety: EN60950-1
Packaging level: IP52
Anti-seismic capacity: This product can still work properly after falling down and being impacted on the concrete floor from the height of 3m for many times

Light source type: Visual lasing diode

The wave length is 650mm

Trigger mode: Manual (can be switched off after the on/off button is pressed for several seconds)

Scanning pattern: Single-line scanning

Scanning speed: 100±2 times/s

Resolution: ≥4mil

Printing contrast ratio: The lowest reflectivity difference is 30％

Bit error rate: 1/50 million

Charging input voltage: 5V DC±0.25V

Power: 100mW (work): 500mW (momentary maximum)

Current: 20mA (work): 100mA (momentary maximum)

Standby current: ＜20uA

Light intensity: 3,000-12,000Lux

Depth of field: 5-630mm

Scanning angle: ±60°±65°±42° (Left and right, front and back, rotation)

Decoding capacity: UPC/EAN/JAN, UPC/EAN with supplemental, UCC/EAN 128, code 39, MSI, code11, Code 39 Full ASCII, code 39 TriOptic, code 128, Code 128Full ASCII, codabar, code93, Discrete2of5, IATA, RSS variants, codabar, Chinese2of5, International general dimensional barcodes, e.g. Inteleaved2/5, Interleaved2of5 and China postal service code

Promotion pattern: Buzzer and LED indicator

Weight: 200g

Charging interface type: RJ-45 crystal head, one meter long (equipped with 5V charger; the battery is being charged when the red light is on and fully charged when the green light is on).

Hull materials: ABS+PC

Temperatures: 0 to 50℃ (Work), -40 to 60℃ (storage)

Setting mode: Manual (scanning and setting barcodes according to the sequence)

Laser safety class: EN60825-1, class 1, national level-I laser safety standard

EMC: EN55022, EN55024

Electrical safety: EN60950-1

Packaging level: IP52

Anti-seismic capacity: This product can still work properly after falling down and being impacted on the concrete floor from the height of 3m for many times
