YT860 Wireless 2.4G Laser Barcode Scanner/Reader, <20mA Standby Current

YT860 Wireless 2.4G Laser Barcode Scanner/Reader, <20mA Standby Current

Get Latest Price

Payment Type:: Bank Transfer, Western Union, PayPal or Escrow

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Bank Transfer, Western Union, PayPal or Escrow

Product Description

Light source type: visual lasing diode, the wavelength is 650nm

Trigger mode: manual (can be switch off after the on/off button is pressed for several seconds)

Scanning pattern: single-line scanning

Scanning speed: 100 ±2 times/second

Resolution: ≥4-mil

Printing contrast ratio: the lowest reflectivity difference is 30%

Bit error rate: 1/5,000 million

Charging input voltage: 5V DC ±0.25V

Power: 100mW (work), 500mW (momentary maximum)

Current: 20mA (work), 100mA (momentary maximum)

Standby current: <20mA

Light intensity: 3,000-12,000 Lux

Depth of field: 5-630mm

Scanning angle: ±60, 65, 42° (left and right, front and back, rotation)

Decoding capacity:

UPC/EAN/JAN, UPC/EAN with supplemental, UCC/EAN 128, Code 39, MSI, code11
Code 39 full ASCII, code 39 TriOptic, code 128, code 128 full ASCII
Codabar, code 93, Discrete 2 of 5, IATA, RSS variants, codabar, Chinese 2 of 5
International general dimensional barcodes, e.g. interleaved 2/5, interleaved 2 of 5, China postal service code and more

Prompt mode: buzzer and LED indicator

Receiving interface: RF is equipped with 2.4G bidirectional wireless digital transmission module

Weight: 200g

Charging interface type:

RJ45 crystal head, one meter length (equipped with 5V charger, the battery is being charged when the red light is on and fully charged when the green light is on)

Hull materials: ABS + PC

Temperature: 0 to 50℃ (work), -40 to 60℃ (storage)

Setting mode: manual (scanning and setting barcodes according to the sequence)

UPC/EAN/JAN, UPC/EAN with supplemental, UCC/EAN 128, Code 39, MSI, code11

Code 39 full ASCII, code 39 TriOptic, code 128, code 128 full ASCII

Codabar, code 93, Discrete 2 of 5, IATA, RSS variants, codabar, Chinese 2 of 5

International general dimensional barcodes, e.g. interleaved 2/5, interleaved 2 of 5, China postal service code and more
