Charge Station 1D Wireless Barcode Scanner, Antenna, 360 Degrees Rotate

Charge Station 1D Wireless Barcode Scanner, Antenna, 360 Degrees Rotate

Get Latest Price

Payment Type:: Telegraphic Transfer in Advance (Advance TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Part number: BM900

Light source type: visual lasing diode

The wave length: 650mm

Trigger mode: manual

Scanning mode: single-line scanning

Scanning speed: 100 ±2 times /second

Resolution: ≥4mil

Printing contrast ratio: The lowest reflectivity difference is 30％

Bit error rate: 1/5million

Input voltage: 5 ±0.25V DC

Power: 100mW (working): 400mW (momentary maximum)

Current: 20mA (working): 100mA (momentary maximum)

Standby current: <20mA

Light intensity: 3,000-12,000 Lux

Depth of field: 5-630mm

Scanning angle: ±60, ±65, ±42° (left and right, front and back, rotation)

Decoding capacity: UPC/EAN/JAN, UPC/EAN with supplemental, UCC/EAN 128, Code 39, MSI, code11

Code 39 full ASCII, code 39 tri optic, code 128, code 128 full ASCII

Codabar, code93, discrete 2 of 5, IATA, RSS variants, codabar, Chinese 2 of 5,

International general dimensional barcodes, e.g. inteleaved2/5, interleaved 2 of 5, China postal service code and so on

Promotion mode buzzer and LED indicator

Cable interface: USB (standard): PS/2 and RS232 are selectable

External dimensions (L*W*H): 158*68*96

Weight: 400g

Cable standard straight line, 1m

Interface type: RJ-45 crystal head

Hull material: ABS + PC

Temperature: 0 to 50℃ (working): -40 to 60℃ (storage)

Setting mode manual (scanning and setting barcodes according to the sequence)

Safety regulations laser safety class: EN60825-1, class 1, state level-I laser safety standard

EMC: EN55022, EN55024

Electrical safety: EN60950-1

Packaging level: IP52

Anti-seismic capacity: this product can still work properly after falling down and being impacted on the concrete floor from the height of 3m for many times
