LKV2300 VGA to Component Video Converter Lenkeng with 5V DC/1A Power Supply, 3W Power Consumption

LKV2300 VGA to Component Video Converter Lenkeng with 5V DC/1A Power Supply, 3W Power Consumption

Get Latest Price

Payment Type:: Telegraphic Transfer (TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer (TT,T/T)

Product Description

Description:

LKV2300 converts VGA to component video, allowing connection of PC/laptop VGA to TV that supports 480, 720P, 1,080i via component video
It is with component video output as well as VGA and offers simultaneous viewing on TV and PC monitor
The VGA output is pass-through without processing, while component video output is with multiple display modes for option

Specifications:

Input: 1 x VGA, 1 x audio
Output: 1 x VGA, 1 x component video, 2 x audio
VGA resolution: 640 x 480 pixels at 60/75Hz, 800 x 600 pixels at 60/75Hz, 1,024 x 768 pixels at 60/75Hz, 1,280 x 800 pixels at 60Hz, 1,280 x 1,024 pixels at 60Hz
Component video resolution: 480, 720P, 1,080i
Optional display mode of component video output normal, vivid, soft, sharp
Recommended VGA and corresponding component video resolution 640 x 480 pixels at 60Hz/75Hz, 480 pixels, 800 x 600 pixels at 60/75Hz, 720P, 1,024 x 768 pixels at 60/75Hz, 720 pixels, 1,080i (between which 720 pixels is better)
1,280 x 800 pixels at 60Hz, 720 pixels, 1,080i (between which 720 pixels is better)
Portable size (L x W x H): 12.8 x 9.4 x 3.4cm
Power supply: 5V DC/1A
Maximum power consumption: 3W
Working temperature: -25-55°C

Notes:

In order to get the best display effect, the VGA resolution recommended is 1,024 x 768 pixels at 60/75Hz and component video resolution is 720 pixels, 1,280 x 1,024 pixels at 60Hz is not recommended if the PC supports any one of the other 4 sets resolution

LKV2300 converts VGA to component video, allowing connection of PC/laptop VGA to TV that supports 480, 720P, 1,080i via component video

It is with component video output as well as VGA and offers simultaneous viewing on TV and PC monitor

The VGA output is pass-through without processing, while component video output is with multiple display modes for option

Input: 1 x VGA, 1 x audio

Output: 1 x VGA, 1 x component video, 2 x audio

VGA resolution: 640 x 480 pixels at 60/75Hz, 800 x 600 pixels at 60/75Hz, 1,024 x 768 pixels at 60/75Hz, 1,280 x 800 pixels at 60Hz, 1,280 x 1,024 pixels at 60Hz

Component video resolution: 480, 720P, 1,080i

Optional display mode of component video output normal, vivid, soft, sharp

Recommended VGA and corresponding component video resolution 640 x 480 pixels at 60Hz/75Hz, 480 pixels, 800 x 600 pixels at 60/75Hz, 720P, 1,024 x 768 pixels at 60/75Hz, 720 pixels, 1,080i (between which 720 pixels is better)

1,280 x 800 pixels at 60Hz, 720 pixels, 1,080i (between which 720 pixels is better)

Portable size (L x W x H): 12.8 x 9.4 x 3.4cm

Power supply: 5V DC/1A

Maximum power consumption: 3W

Working temperature: -25-55°C

In order to get the best display effect, the VGA resolution recommended is 1,024 x 768 pixels at 60/75Hz and component video resolution is 720 pixels, 1,280 x 1,024 pixels at 60Hz is not recommended if the PC supports any one of the other 4 sets resolution
