SDI to HDMI Converter with 48kHz Digital Audio

SDI to HDMI Converter with 48kHz Digital Audio

Get Latest Price

Payment Type:: Telegraphic Transfer (TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer (TT,T/T)

Product Description

Introduction:

Converts SDI or HD-SDI to HDMI for driving HDMI monitors
It is just for video format conversion and doesn’t change resolution
With high-quality picture output and fast transmission and is an easy/cost-effective solution for SDI to HDMI conversion
Audio output is integrated in to the HDMI output

Features:

Input: SDI x 1
Output: HDMI x 1
Auto detect resolution of HD-SDI, SD-SDI and 3G-SDI
Full HDMI supported with embedded audio
Synchronized output audio video and audio
Plug and play function

Specifications:

SDI input
Format: Auto detect resolution of HD-SDI, SD-SDI and 3G-SDI
Date rate: 270Mb/s, 1.485Gb/s, 2.97Gb/s
Impedance: 75Ω
Receive ability:
- SD-SDI signal is as far as 460 meters away
- HD-SDI is as far as 230 meters away
Resolutions: SD 525i, 625i; HD720P at 24Hz, 720P at 25Hz, 720P at 30Hz, 720P at 50Hz, 720P at 60Hz, HD 1,080i at 50Hz, 1,080i at 60Hz, HD 1,080P at 24Hz, 1,080P at 25Hz, 1,080P at 30Hz, 1080P at 50Hz and 1,080P at 60Hz
Audio: 48kHz digital audio
Power: DC 5V/1A
Working currency is less than 400mA

Converts SDI or HD-SDI to HDMI for driving HDMI monitors

It is just for video format conversion and doesn’t change resolution

With high-quality picture output and fast transmission and is an easy/cost-effective solution for SDI to HDMI conversion

Audio output is integrated in to the HDMI output

Input: SDI x 1

Output: HDMI x 1

Auto detect resolution of HD-SDI, SD-SDI and 3G-SDI

Full HDMI supported with embedded audio

Synchronized output audio video and audio

Plug and play function

SDI input

Format: Auto detect resolution of HD-SDI, SD-SDI and 3G-SDI

Date rate: 270Mb/s, 1.485Gb/s, 2.97Gb/s

Impedance: 75Ω

Receive ability:

SD-SDI signal is as far as 460 meters away
HD-SDI is as far as 230 meters away

Resolutions: SD 525i, 625i; HD720P at 24Hz, 720P at 25Hz, 720P at 30Hz, 720P at 50Hz, 720P at 60Hz, HD 1,080i at 50Hz, 1,080i at 60Hz, HD 1,080P at 24Hz, 1,080P at 25Hz, 1,080P at 30Hz, 1080P at 50Hz and 1,080P at 60Hz

Audio: 48kHz digital audio

Power: DC 5V/1A

Working currency is less than 400mA

SD-SDI signal is as far as 460 meters away

HD-SDI is as far as 230 meters away
