SDI to HDMI® HD Converter, 1,080P with Audio Output 5V/1A Power

SDI to HDMI® HD Converter, 1,080P with Audio Output 5V/1A Power

Get Latest Price

Payment Type:: T/T, PayPal, L/C or Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, PayPal, L/C or Western Union

Product Description

Descriptions:

It SDI to HDMI® converter converts SDI or HD SDI toHDMI® for driving HDMI® monitors
Embedded SDI/HD SDI audio is supported in the HDMI® outputallowing a convenient single cable audio/video connection
Auto detect resolution of HD SDI, SD SDI and 3G SDI
Full HDMI® supported with embedded audio
Synchronized output audio video and audio
Plug-and-play function

Specifications:

Format: auto detect resolution of HD SDI, SD SDI and 3GSDI
Date rate: 270Mbps, 1.485Gbps, 2.97Gbps
Impedance: 75©
Receive ability:
- SD SDI signal is as far as 460 meters away
- HD SDI is as far as 230 meters away
Resolution: SD 525i, 625i, HD720P at 24Hz, 720P at 25Hz, 720Pat 30Hz, 720P at 50Hz, 720P at 60Hz, HD 1,080i at 50Hz, 1080i at60Hz, HD 1,080P at 24Hz, 1,080P at 25Hz, 1,080P at 30Hz, 1,080P at50Hz, 1,080P at 60Hz
Audio: 48kHz digital audio
Power: 5V DC/1A, working currency is less than 400milli-amphere
Dimensions: 105 x 59 x 23mm
Weight: 75g

It SDI to HDMI® converter converts SDI or HD SDI toHDMI® for driving HDMI® monitors

Embedded SDI/HD SDI audio is supported in the HDMI® outputallowing a convenient single cable audio/video connection

Auto detect resolution of HD SDI, SD SDI and 3G SDI

Full HDMI® supported with embedded audio

Synchronized output audio video and audio

Plug-and-play function

Format: auto detect resolution of HD SDI, SD SDI and 3GSDI

Date rate: 270Mbps, 1.485Gbps, 2.97Gbps

Impedance: 75©

Receive ability:

SD SDI signal is as far as 460 meters away
HD SDI is as far as 230 meters away

Resolution: SD 525i, 625i, HD720P at 24Hz, 720P at 25Hz, 720Pat 30Hz, 720P at 50Hz, 720P at 60Hz, HD 1,080i at 50Hz, 1080i at60Hz, HD 1,080P at 24Hz, 1,080P at 25Hz, 1,080P at 30Hz, 1,080P at50Hz, 1,080P at 60Hz

Audio: 48kHz digital audio

Power: 5V DC/1A, working currency is less than 400milli-amphere

Dimensions: 105 x 59 x 23mm

Weight: 75g

SD SDI signal is as far as 460 meters away

HD SDI is as far as 230 meters away
