Cable Assembly, High-density Polythene, 7 Copper Wires Conductor, 75°C Rated Temperature
  • Cable Assembly, High-density Polythene, 7 Copper Wires Conductor, 75°C Rated Temperature
  • Cable Assembly, High-density Polythene, 7 Copper Wires Conductor, 75°C Rated Temperature
  • Cable Assembly, High-density Polythene, 7 Copper Wires Conductor, 75°C Rated Temperature
Cable Assembly, High-density Polythene, 7 Copper Wires Conductor, 75°C Rated Temperature
Cable Assembly, High-density Polythene, 7 Copper Wires Conductor, 75°C Rated Temperature
Cable Assembly, High-density Polythene, 7 Copper Wires Conductor, 75°C Rated Temperature

Cable Assembly, High-density Polythene, 7 Copper Wires Conductor, 75°C Rated Temperature

Get Latest Price
Payment Type:
L/C or T/T
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: L/C or T/T
Product Description
Product Description
  • Specifications:
    • Conductor: 7 x 24AWG (7/0.2mm) stranded copper/CCA/CCS
    • Path cord plug: RJ-45 plug 8P8C
    • Boot: FR PVC high-injection
    • Insulation: HD-PE
    • Jacket: PVC
    • Nominal OD: 5.3mm
    • Color codes:
      • Pair 1: white/blue and blue
      • Pair 2: white/orange and orange
      • Pair 3: white/green and green
      • Pair 4: white/brown and brown
    • Lengths: 0.5, 1, 2, 3 and 5m (special length are accepted)
    • LAN cable standard compliance category: 5TIA/EIA-568-B-2.1
    • Certificates: CE and RoHS
    • ODM and OEM services are provided
  • Applications:
    • Improved attenuation provides cleaner data and video transmissions
    • For 1000Base-T, 100Base-TX, 155Mbps ATM and other high-speed applications
    • Designed for LAN network system and computer networks
    • Distributing system, telecommunications network system, testing equipment system and CATV system
    • 24AWG: 7/0.20, 26AWG: 7/0.16, 28AWG: 7/0.12 and 30AWG: 7/0.1
  • Features:
    • Fast and convenient connection
    • Perfect combination of high-quality Cat5e cable and RJ45 connector
    • Multiple strands conductor insures excellent reliability and stability
    • Colors: gray, blue, yellow and red or as per your requirements
    • Length: 1, 2, 3, 5, 10, 20 and 30m or as per your requirements
  • Packing: 1 piece/polybag
  • Conductor: 7 x 24AWG (7/0.2mm) stranded copper/CCA/CCS
  • Path cord plug: RJ-45 plug 8P8C
  • Boot: FR PVC high-injection
  • Insulation: HD-PE
  • Jacket: PVC
  • Nominal OD: 5.3mm
  • Color codes:
    • Pair 1: white/blue and blue
    • Pair 2: white/orange and orange
    • Pair 3: white/green and green
    • Pair 4: white/brown and brown
  • Lengths: 0.5, 1, 2, 3 and 5m (special length are accepted)
  • LAN cable standard compliance category: 5TIA/EIA-568-B-2.1
  • Certificates: CE and RoHS
  • ODM and OEM services are provided
  • Pair 1: white/blue and blue
  • Pair 2: white/orange and orange
  • Pair 3: white/green and green
  • Pair 4: white/brown and brown
  • Improved attenuation provides cleaner data and video transmissions
  • For 1000Base-T, 100Base-TX, 155Mbps ATM and other high-speed applications
  • Designed for LAN network system and computer networks
  • Distributing system, telecommunications network system, testing equipment system and CATV system
  • 24AWG: 7/0.20, 26AWG: 7/0.16, 28AWG: 7/0.12 and 30AWG: 7/0.1
  • Fast and convenient connection
  • Perfect combination of high-quality Cat5e cable and RJ45 connector
  • Multiple strands conductor insures excellent reliability and stability
  • Colors: gray, blue, yellow and red or as per your requirements
  • Length: 1, 2, 3, 5, 10, 20 and 30m or as per your requirements
