19 Inches RJ45 Network Cat5e Patch Panels, 150V Voltage Rating

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer (TT,T/T)

Product Description

Descriptions:

Specifications:

Electrical:

Materials:

Housing: PC UL94V-0
IDC: PC UL94V-0, accept 22-26AWG solid wire
PCB: FR4 1.6mm (0.04-inch) thickness, 2 layers
Contact: PC UL94V-0, 0.45mm (0.018-inch) diameter phosphor bronze with 3-50U-inch
Gold plating on contact area

12/16/18/24/48 ports patch panel

OEM, ODM orders are available

With RoHS, CE, FCC, UL, ETL marks

Size: 1U, 2U 19-inch

110 IDC patch panel

Meet TIA/EIA-568-A and TIA/EIA-568-B Category 5E requirements

Meet TIA/EIA TSB-40

Meet CENELEC generic cabling standard EN50173

Angle: 90,180 degrees

Termination: 110 type

Current rating: 1.5A (maximum)

Voltage rating: 150V

Contact resistance: 20m Ohms

Insulation resistance: 500M Ohms

Dielectric withstand voltage: 1,000V AC RMS, 60Hz 1 minute

Housing: PC UL94V-0

IDC: PC UL94V-0, accept 22-26AWG solid wire

PCB: FR4 1.6mm (0.04-inch) thickness, 2 layers

Contact: PC UL94V-0, 0.45mm (0.018-inch) diameter phosphor bronze with 3-50U-inch

Gold plating on contact area
