Coaxial Cables with 2-cord Power Cable, PVC Jacket, Copper/CCS Conductor, 1,000ftNew

Coaxial Cables with 2-cord Power Cable, PVC Jacket, Copper/CCS Conductor, 1,000ftNew

Get Latest Price

Payment Type:: T/T, Western Union or L/C at Sight

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, Western Union or L/C at Sight

Product Description

Features:

0.81mm bare copper (or CCS) + 3.66mm foamed PE + A/P (bonded) +60% Al braiding/copper braiding + 6.10mm PVC
2C power cable
Conductor material: stranded copper
Conductor diameter: 18 AWG, 7 x 0.39 or 16 x 0.25mm
Dielectric: solid PE
Customized specifications are accepted
Customized requirements are accepted
Conductor: solid bare copper/copper clad steel
Conductor diameter: 0.81mm/more
Insulation: foam PE/solid PE
Foil: aluminum/copper
2C power cable conductor material: stranded copper
C power cable conductor diameter: 18 AWG, 7 x 0.39 or 16 x 0.25mm
Braiding material: AL-mg/copper/aluminum
Braiding quantity: 64/96/112/128
Jacket: PVC/PE

Note:

Center conductor: tinned copper, bare copper and copper clad steel are available
Al-foil: non-bonded aluminum foil, bonded aluminum foil, double bonded AL-foil and double non-bonded AL-foil are available
Braiding wire: aluminum, bare copper and tinned copper are available
Braiding wire diameter: 0.10, 0.12, 0.13, 0.14, 0.15, 0.16mm are available
Braiding net: 32, 48, 64, 72, 80, 96, 120, 128, 144mm and more are available
Braiding coverage: between 30-97% are available
PVC jacket of flame-retardant, UV or UL available, commonly used 75© cable can be used in applications where cable assemblies must be built-in the field, solid 18 AWG center conductor results in a cable with very low-attenuation properties, 18 AWG, copper-covered steel wire insulated with HDPE, shield with 100% Al foil and 60% Al braiding, jacket material is UL-rated PV

Packing:

Packaging: neutral packaging/logo packaging
Ways: 305/100m/more
Style: wooden roller/more

0.81mm bare copper (or CCS) + 3.66mm foamed PE + A/P (bonded) +60% Al braiding/copper braiding + 6.10mm PVC

2C power cable

Conductor material: stranded copper

Conductor diameter: 18 AWG, 7 x 0.39 or 16 x 0.25mm

Dielectric: solid PE

Customized specifications are accepted

Customized requirements are accepted

Conductor: solid bare copper/copper clad steel

Conductor diameter: 0.81mm/more

Insulation: foam PE/solid PE

Foil: aluminum/copper

2C power cable conductor material: stranded copper

C power cable conductor diameter: 18 AWG, 7 x 0.39 or 16 x 0.25mm

Braiding material: AL-mg/copper/aluminum

Braiding quantity: 64/96/112/128

Jacket: PVC/PE

Center conductor: tinned copper, bare copper and copper clad steel are available

Al-foil: non-bonded aluminum foil, bonded aluminum foil, double bonded AL-foil and double non-bonded AL-foil are available

Braiding wire: aluminum, bare copper and tinned copper are available

Braiding wire diameter: 0.10, 0.12, 0.13, 0.14, 0.15, 0.16mm are available

Braiding net: 32, 48, 64, 72, 80, 96, 120, 128, 144mm and more are available

Braiding coverage: between 30-97% are available

PVC jacket of flame-retardant, UV or UL available, commonly used 75© cable can be used in applications where cable assemblies must be built-in the field, solid 18 AWG center conductor results in a cable with very low-attenuation properties, 18 AWG, copper-covered steel wire insulated with HDPE, shield with 100% Al foil and 60% Al braiding, jacket material is UL-rated PV

Packaging: neutral packaging/logo packaging

Ways: 305/100m/more

Style: wooden roller/more
