DVB-T2 Receiver with One USB2.0 and HDMI, MPEG-4/H.264 DVB-T2

Get Latest Price

Payment Type:: Telegraphic Transfer (TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer (TT,T/T)

Product Description

DVB-T2 receiver with one USB2.0 and HDMI

Solution: Mstar7816 or ali3812

Fully DVB-T/DVB-T2, MEPG-2/4 H.264 HD/SD compliant

Compatible with 576i/576P/720P/1,080i/1,080P video formats

Auto and manually scan all available TV and radio channels

Aspect ratio: 16:9 and 4:3

HDMI, SCART output

Multi-language subtitle output: supported

Powerful and highly effective 7-day EPG function

Supports teletext

Parental lock

PVR ready function via USB2.0 (optional)

Multimedia playback via USB2.0 (optional)

Stores up to 1,000 programs and keeps in memory while power-off

Basic features:

Operating temperature: 0~40°C
Input voltage: 100~240V, 50/60Hz
Power consumption: 8W (maximum)
OSD languages: multi

Tuner:

IF input frequency UHF: 474~860MHz
Bandwidth: 8MHz
Input impedance: 75Ω
Input level: 77 to -10dBm
Signal input IEC type: female MPEG transport stream and A/V decoding
Video standard: MPEG-4 AVC/H.264 HP at L4
SCART video model: CVBS/RGB
Aspect ratio: 4:3, 16:9
Video resolution: 480i/480P/576i, 576P, 720 and 1,080i
Audio standard: IEC 14.496-3, AC3, AAC, AAC+
Audio modes: mono, dual-channel, stereo

Multimedia formats:

Picture: JPEG
Audio: MP3
Video: DivX

Front panel: LED display

USB firmware upgrade PVR and multimedia playback

Channel decoding: standard DVB-T

Demodulation: QPSK, 16QAM, 64QAM

FEC: 1/2, 2/3, 3/4, 5/6, 7/8, automatic

Guard: 1/4, 1/8, 1/16, 1/32

Mode: 2, 4, 8K

Demultiplexer:

Standard: IEC 13818-1, ARIB STB-B10
Input: bit stream rate 120Mbps (serial)/15Mbps (parallel)

Rear panel output:

HDMI 480i/480P/576i, 576, 720P and 1,080i
Loop through output: IEC-type, connector, signal tuner

Operating temperature: 0~40°C

Input voltage: 100~240V, 50/60Hz

Power consumption: 8W (maximum)

OSD languages: multi

IF input frequency UHF: 474~860MHz

Bandwidth: 8MHz

Input impedance: 75Ω

Input level: 77 to -10dBm

Signal input IEC type: female MPEG transport stream and A/V decoding

Video standard: MPEG-4 AVC/H.264 HP at L4

SCART video model: CVBS/RGB

Aspect ratio: 4:3, 16:9

Video resolution: 480i/480P/576i, 576P, 720 and 1,080i

Audio standard: IEC 14.496-3, AC3, AAC, AAC+

Audio modes: mono, dual-channel, stereo

Picture: JPEG

Audio: MP3

Video: DivX

Standard: IEC 13818-1, ARIB STB-B10

Input: bit stream rate 120Mbps (serial)/15Mbps (parallel)

HDMI 480i/480P/576i, 576, 720P and 1,080i

Loop through output: IEC-type, connector, signal tuner
