800TVL IR-cut High-definition IR Camera
  • 800TVL IR-cut High-definition IR Camera
800TVL IR-cut High-definition IR Camera

800TVL IR-cut High-definition IR Camera

Get Latest Price
Payment Type:
Advance T/T or PayPal
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: Advance T/T or PayPal
Product Description
Product Description
  • Features:
    • Color has a high-sensitivity DIS image sensor, It shows superior image effects
    • High resolution, BLC, AGC, AWB, mirror function
    • Housing is made of special material
    • Waterproof is up to IP66 level
    • Third generation of IR array illuminant, which can improve the photoelectric conversion efficiency
    • IR LED lifetime is more than five years and night-vision has an effective result
    • Uses accurate constant current source technology
    • The LED board is designed to separate from the control circuit board, to make it more stable
    • High-powered lighting protection circuit, to make the CCD board more stable
  • Specifications:
    • Image sensor: 1/4 DIS
    • CCD total pixel:
      P:720 (H) x 480 (V)
      N: 720 (H) x 480 (V)
    • Sync system: internal
    • Minimum illumination: 1lux F1.2/0lux (IR-on)
    • Resolution: 800TVL
    • Lens: F1.2/16mm, F1.2/12mm
    • IR distance: 0-80m
    • IR LED: 2pcs
    • WBC: auto
    • AG: AGC
    • S/N ratio: ≥48dB
    • Exposure time: auto
    • Auto-iris: electronic shutter
    • Mirror function: on/off (optional)
    • BLC: on/off (optional)
    • Video output: 1.0Vp-p/75Ω
    • Gamma correction: 0.45
    • Working temperature: -20 to 50°C
    • Working humidity: 85%RH
    • Power supply: DC 12V
    • Power consumption: ≤450mA
    • Measurement: 270 x 110 x 130mm
  • Color has a high-sensitivity DIS image sensor, It shows superior image effects
  • High resolution, BLC, AGC, AWB, mirror function
  • Housing is made of special material
  • Waterproof is up to IP66 level
  • Third generation of IR array illuminant, which can improve the photoelectric conversion efficiency
  • IR LED lifetime is more than five years and night-vision has an effective result
  • Uses accurate constant current source technology
  • The LED board is designed to separate from the control circuit board, to make it more stable
  • High-powered lighting protection circuit, to make the CCD board more stable
  • Image sensor: 1/4 DIS
  • CCD total pixel:
    P:720 (H) x 480 (V)
    N: 720 (H) x 480 (V)
  • Sync system: internal
  • Minimum illumination: 1lux F1.2/0lux (IR-on)
  • Resolution: 800TVL
  • Lens: F1.2/16mm, F1.2/12mm
  • IR distance: 0-80m
  • IR LED: 2pcs
  • WBC: auto
  • AG: AGC
  • S/N ratio: ≥48dB
  • Exposure time: auto
  • Auto-iris: electronic shutter
  • Mirror function: on/off (optional)
  • BLC: on/off (optional)
  • Video output: 1.0Vp-p/75Ω
  • Gamma correction: 0.45
  • Working temperature: -20 to 50°C
  • Working humidity: 85%RH
  • Power supply: DC 12V
  • Power consumption: ≤450mA
  • Measurement: 270 x 110 x 130mm
