Product Description

Capacities:

Maximum swing over bed: 360mm

Maximum swing over cross slide: 185mm

Maximum swing in gap: 490mm

Center distance: 750, 1,000, 1,500, and 2,000mm

Cross slide travel: 330mm

Spindle:

Spindle hole: 80mm

Spindle nose: ISO-C8 or ISO-D8

Spindle taper metric: 85mm

Spindle speeds: 24 to 1,600rpm (15 steps)

Feeds:

Metric threads range: 0.5 to 28mm (66 kinds)

Inch threads range: 1 to 56tpi (66 kinds)

Module threads range: 0.5 to 3.5mm (33 kinds)

Diameter threads range: 8 to 56tpi (33 kinds)

Tailstock:

Spindle diameter: 65mm

Spindle taper: morse number 5

Spindle travel: 120mm

Main motor: 5.5 to 7.75kW

Net/gross weight: 1,000mm, 1,520/2,170kg, 1,500mm, 1,750/2,390kg 2000mm 1,950/2,760kg

Packaging size:

1,000mm: 2,460 x 1,150 x 1,800mm

1,500mm: 2,950 x 1,150 x 1,800mm

2,000mm: 3,460 x 1,150 x 1,800mm
