Machine Tool with Spindle Nose of D1-4 and 38mm Bore
  • Machine Tool with Spindle Nose of D1-4 and 38mm Bore
Machine Tool with Spindle Nose of D1-4 and 38mm Bore

Machine Tool with Spindle Nose of D1-4 and 38mm Bore

Get Latest Price
Payment Type:
Telegraphic Transfer in Advance (Advance TT, T/T)
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: Telegraphic Transfer in Advance (Advance TT, T/T)
Product Description
Product Description
  • Model: C0632A x 1000/C0636A x 1000
  • Capacity: swing over bed: 330mm (13-inch)/360mm (14-inch)
  • Swing over cross slide: 198mm (7-25/32-inch)/224mm(18-13/16-inch)
  • Swing in gap: 476mm (18-3/4-inch)/502mm (19-3/4-inch)
  • Distance between centers: 1,000mm (40-inch)/1,000mm(40-inch)
  • Valid length of gap: 125mm (5-inch)
  • Width of bed: 187mm (7-3/8-inch)
  • Headstock:
    • Spindle nose: D1-4
    • Spindle bore: 38mm (1-1/2-inch)
    • Taper of spindle bore: No.5 Morse
    • Range of spindle speed: 8 changes 70 to 2,000rpm
  • Feeds and threads:
    • Maximum travel of top slide: 95mm (3-3/4-inch)
    • Maximum travel of cross slide: 170mm(6-11/16-inch)
    • Maximum section of tool: 16 x 16mm (5/8 x 5/8-inch)
    • Pitch thread of lead screw: 8 TPI/3mm
    • Longitudinal feeds range: 0.002 to 0.0548-inch/rev/0.052 to1.392mm/rev
    • Cross feeds range: 0.0007 to 0.0187-inch/rev/0.a014 to0.38mm/rev
    • Metric threads range: 0.4 to 7mm
    • Inch threads range: 4 to 56 TPI
  • Tail stock:
    • Dia. of tail stock sleeve: 32mm (1-1/4-inch)
    • Travel of tail stock sleeve: 100mm(4-inch)
    • Taper of tail stock sleeve: No.3 Morse
  • Motor:
    • Power of main motor: 1.5kW(2HP)
  • Dimensions and weight:
    • Overall dimensions (L x W x H): 1,820 x 6,80x 1,310mm/1,820 x680 x 1,320mm
    • Packing size (L x W x H): 1,930 x 760 x 1,590mm/1,930 x 760 x1,590mm
    • Net weight: 550/610kg
    • Gross weight: 650/710kg
  • Standard accessories:
    • Three jaw chuck
    • Four jaw chuck
    • Face plate
    • Tool box and tools 1 set
    • Steady rest
    • Follow rest
  • Optional accessories:
    • Live center
    • Taper turning attachment
    • Coolant system
    • Quick change tool post and holders
    • Brake
    • Lamp
  • Spindle nose: D1-4
  • Spindle bore: 38mm (1-1/2-inch)
  • Taper of spindle bore: No.5 Morse
  • Range of spindle speed: 8 changes 70 to 2,000rpm
  • Maximum travel of top slide: 95mm (3-3/4-inch)
  • Maximum travel of cross slide: 170mm(6-11/16-inch)
  • Maximum section of tool: 16 x 16mm (5/8 x 5/8-inch)
  • Pitch thread of lead screw: 8 TPI/3mm
  • Longitudinal feeds range: 0.002 to 0.0548-inch/rev/0.052 to1.392mm/rev
  • Cross feeds range: 0.0007 to 0.0187-inch/rev/0.a014 to0.38mm/rev
  • Metric threads range: 0.4 to 7mm
  • Inch threads range: 4 to 56 TPI
  • Dia. of tail stock sleeve: 32mm (1-1/4-inch)
  • Travel of tail stock sleeve: 100mm(4-inch)
  • Taper of tail stock sleeve: No.3 Morse
  • Power of main motor: 1.5kW(2HP)
  • Overall dimensions (L x W x H): 1,820 x 6,80x 1,310mm/1,820 x680 x 1,320mm
  • Packing size (L x W x H): 1,930 x 760 x 1,590mm/1,930 x 760 x1,590mm
  • Net weight: 550/610kg
  • Gross weight: 650/710kg
  • Three jaw chuck
  • Four jaw chuck
  • Face plate
  • Tool box and tools 1 set
  • Steady rest
  • Follow rest
  • Live center
  • Taper turning attachment
  • Coolant system
  • Quick change tool post and holders
  • Brake
  • Lamp
