LED Street Light, 25W Meanwell Driver, IP65, 5-year Warranty

LED Street Light, 25W Meanwell Driver, IP65, 5-year Warranty

Get Latest Price

Payment Type:: T/T, L/C, Western Union, PayPal

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, L/C, Western Union, PayPal

Product Description

More than 70% energy saving

4 x 7 LED module design, convenient for maintenance

Original American Bridgelux LED or Cree/Philips Lumileds LED used

Universal input voltages: AC 85-265V/277V /DC10-28V

Light control and time-phase dimming, saving further energy

High quality power supply, reliable and stable

Automatically reduce current against overheating temperature

Unique optical design & rectangular beam, suitable for roadway illumination

Lux is proud of its high power LED street light series: High power LED street lights are new series of energy saving products that utilize high power LEDs as effective lighting source to traditional illumination

Based on the classic modular design-our first generation LED street light, our upgraded generation improves the module design as 4 × 7 arrays

Although LEDs were deducted, but the light efficiency is much higher and much more effective based on the dual lens design, this kind of design has really achieved a high luminous efficiency, low power consumption and excellent heat dissipation characteristics

By scientific calculating, the whole lamp lighting efficiency can raise by 20%, temperature rising can be decreased by 20% and the energy saving rate can be increased by 20%.

Applications：

LED street light is available for main roads, sidewalks, squares, school parks, gardens, factories, residential places, villas and many other projector lighting places

Main technology indexes:

Model No. LX-SL24
Equivalent 70W high pressure sodium lamp
LED light source: 24 × 1W Cree LED/Philips Lumileds
LED luminous efficiency: 107-122 lm/w
Lamp total power: 30W
Power efficiency: 87%
Lamp rated luminous flux:＞2,500lm
Lamp rated luminous efficiency:＞95lm/W
Average illumination & effective area:
- 4M height: 13m×5m ≥28lux
- 6M height: 20m×8m ≥15lux
- 8M height: 26m×10m ≥11lux
Color rendering index (CRI): Ra>75
Color temperatures:
- Cool white: 5,700K
- Pure white: 4,500K
- Warm white: 3,000K
Beam angle: 140 x 75°
Light distribution curve (beam pattern)
Asymmetric (bat wing)/rectangular beam
Input voltage: AC 85-265V/277V, DC 10-28V
Frequency range: 47-63Hz
Power factor (PF): 0.96
Total harmonic distortion (THD): < 15%
Storage temperatures: －40--80℃
Working environments: －40--50℃, 10-95%RH
Junction temperatures (Tj): 60℃ ± 10%

LED street light is available for main roads, sidewalks, squares, school parks, gardens, factories, residential places, villas and many other projector lighting places

Model No. LX-SL24

Equivalent 70W high pressure sodium lamp

LED light source: 24 × 1W Cree LED/Philips Lumileds

LED luminous efficiency: 107-122 lm/w

Lamp total power: 30W

Power efficiency: 87%

Lamp rated luminous flux:＞2,500lm

Lamp rated luminous efficiency:＞95lm/W

Average illumination & effective area:
