Diameter 32mm12v dc worm gear motor for massage

Get Latest Price

Payment Type:: T/T, Paypal

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, Paypal

Product Description

Dimensions:

gear box size: 46.0 * 32.0* 23.0mm
motor size:dia 24*30.8mm
Shaft diameter: 6.0mm
Shaft length: 15mm or customized with flat position:12*0.5mm

Characteristics:

No load current: 0.02A
Stall current: 0.46A
Torque:1.5-10 kg.cm
Rated speed:1.5-20 rpm
Stall torque: 3-15 kg.cm
Voltage: 12VDC
Delivery details: 20-25 days
Reduction ratio: 146、188、300、438、563、700、900、1020、1313、1688、2700
Samples can be sent first and the delivery time is 15-20 days
Shaft diameter can be customized

Usage:

Garbage disposers,Water IC card,Toys and gifts, Kind of figer-electronic locks,Optical equipment, Card conveyors,Robots,Towel dispensers, Office equipment, Household appliances, Automatic actuator.

gear box size: 46.0 * 32.0* 23.0mm

motor size:dia 24*30.8mm

Shaft diameter: 6.0mm

Shaft length: 15mm or customized with flat position:12*0.5mm

No load current: 0.02A

Stall current: 0.46A

Torque:1.5-10 kg.cm

Rated speed:1.5-20 rpm

Stall torque: 3-15 kg.cm

Voltage: 12VDC

Delivery details: 20-25 days

Reduction ratio: 146、188、300、438、563、700、900、1020、1313、1688、2700

Samples can be sent first and the delivery time is 15-20 days

Shaft diameter can be customized

Garbage disposers,Water IC card,Toys and gifts, Kind of figer-electronic locks,Optical equipment, Card conveyors,Robots,Towel dispensers, Office equipment, Household appliances, Automatic actuator.
