CCTV Camera Plug Adapters, 50 to 60Hz Frequency, 100 to 240V Input Voltage

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T

Product Description

100% full loading burn-in test

All using 105°C long lifespan electrolytic capacitors

Input voltage: 100 to 240V AC

Frequency: 50/60Hz, 1.5A

Line regulation range: ±0.5 (maximum)

Start-up current: 40A/230V AC

Output: 12V, 3A, 4 output

Line regulation range: ±0.5% (maximum)

Ripple and noise: <1% (mVp-p) of output voltage

Adjustable range of output voltage: +5, -3%

Start-up time: d1 second (AC input 240V and Io = 100%)

Hold-up time: e20 minutes (AC input 240V and Io = 100%)

Protections:

Overloading: 115 to 150% of rated power, when it happened, thepower shutdown automatically, when trouble removed the powerrecovers itself
Over-voltage: 130 to 150% of rated voltage
Short-circuit

Insulation intensity:

Insulation resistance:

Operating temperature: 0 to 40°C

Operating humidity range: 10 to 90% RH (no freezing dew)

Storage temperature: -20 to 85°C

Storage humidity range: 10 to 95% RH (no freezing dew)

Elevation: <3,000m

Dimensions (L x W x H): 96 x 52 x 31mm

Weight: 200g

EMC: EN55022, GB3954

Overloading: 115 to 150% of rated power, when it happened, thepower shutdown automatically, when trouble removed the powerrecovers itself

Over-voltage: 130 to 150% of rated voltage

Short-circuit

Input to output: 3,000V/10mA, 60 seconds

Input to output: 500V DC
