24W LED Power Supply with 100-240VAC, 12V 2A/24 V1A, Used for LED Lights and LED Screen
  • 24W LED Power Supply with 100-240VAC, 12V 2A/24 V1A, Used for LED Lights and LED Screen
  • 24W LED Power Supply with 100-240VAC, 12V 2A/24 V1A, Used for LED Lights and LED Screen
24W LED Power Supply with 100-240VAC, 12V 2A/24 V1A, Used for LED Lights and LED Screen
24W LED Power Supply with 100-240VAC, 12V 2A/24 V1A, Used for LED Lights and LED Screen

24W LED Power Supply with 100-240VAC, 12V 2A/24 V1A, Used for LED Lights and LED Screen

Get Latest Price
Payment Type:
T/T
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: T/T
Product Description
Product Description
  • Features:
    • Power: 27W
    • Input range: 100 to 240V AC
    • Output: 12V DC, 2A
    • AC input between the two poles
    • With SCP/OCP/OVP/OTP
    • Class II standard, high-insulation
    • Power consumption (without load) is less than 0.5W
    • With RoHS mark
    • Environments:
      • Working temperatures: -10 to 40
      • Storage temperatures: -25 to 75
      • Related humidity range: 20 to 90% RH
    • Cooling method: cooling by air convection
    • Elevation: d3,000m
  • Electrical characteristics:
    • Input:
      • Rated input voltage range: 100 to 240V AC
      • Input voltage range: 90 to 264V AC
      • Input current: <0.8A
      • Power consumption: 0.5W, 100 to 240V AC input
      • Power factor: -PF
      • Input frequency range: 50 to 60Hz
      • Efficiency: ≤75%
    • Output:
      • Voltage without load: 12V DC, +5%
      • Loading range: 0 to 1.5A
      • Ripple: <30mV
      • Peak :<80mV
      • Start time: ≥3S, 220V AC and IO = 100%
      • Hold up time: ≤20mS, 220V AC and IO = 100%
    • Protections:
      • OCP: rated current 150 to 200%
      • SCP: short circuit power is 0.5W (minimum), recoverable
      • OVP: 13V (unrecoverable)
  • Power: 27W
  • Input range: 100 to 240V AC
  • Output: 12V DC, 2A
  • AC input between the two poles
  • With SCP/OCP/OVP/OTP
  • Class II standard, high-insulation
  • Power consumption (without load) is less than 0.5W
  • With RoHS mark
  • Environments:
    • Working temperatures: -10 to 40
    • Storage temperatures: -25 to 75
    • Related humidity range: 20 to 90% RH
  • Cooling method: cooling by air convection
  • Elevation: d3,000m
  • Working temperatures: -10 to 40
  • Storage temperatures: -25 to 75
  • Related humidity range: 20 to 90% RH
  • Input:
    • Rated input voltage range: 100 to 240V AC
    • Input voltage range: 90 to 264V AC
    • Input current: <0.8A
    • Power consumption: 0.5W, 100 to 240V AC input
    • Power factor: -PF
    • Input frequency range: 50 to 60Hz
    • Efficiency: ≤75%
  • Output:
    • Voltage without load: 12V DC, +5%
    • Loading range: 0 to 1.5A
    • Ripple: <30mV
    • Peak :<80mV
    • Start time: ≥3S, 220V AC and IO = 100%
    • Hold up time: ≤20mS, 220V AC and IO = 100%
  • Protections:
    • OCP: rated current 150 to 200%
    • SCP: short circuit power is 0.5W (minimum), recoverable
    • OVP: 13V (unrecoverable)
  • Rated input voltage range: 100 to 240V AC
  • Input voltage range: 90 to 264V AC
  • Input current: <0.8A
  • Power consumption: 0.5W, 100 to 240V AC input
  • Power factor: -PF
  • Input frequency range: 50 to 60Hz
  • Efficiency: ≤75%
  • Voltage without load: 12V DC, +5%
  • Loading range: 0 to 1.5A
  • Ripple: <30mV
  • Peak :<80mV
  • Start time: ≥3S, 220V AC and IO = 100%
  • Hold up time: ≤20mS, 220V AC and IO = 100%
  • OCP: rated current 150 to 200%
  • SCP: short circuit power is 0.5W (minimum), recoverable
  • OVP: 13V (unrecoverable)
