Description:

An unmanaged fast-Ethernet switch, is designed for residentialbuilding in the corridor-level broadband switching equipment, forthe edge of the access and LAN to provide high-quality networkconnections
It is a case-shaped device with a chassis of 1U high, itprovides 5 10/100Base-TX ports, it provides 4 PoE Injector

Specifications:

Summarize:
- Fixed port: 5 10/100/1,000Base-TX ports
- LED indicators: PWR, PoE, Link/Act VLAN LED
- Input voltage: 100 to 240V AC50/60Hz
- Power consumption: 72W (62W for PoE)
- Operating temperature: 0 to 40 degrees Celsius
- Storage temperature: -10 to 70 degrees Celsius
- Relative humidity: 20 to 85% RH (non-condensing)
- Thermal methods: built-in noiseless FAN
- Switching capacity: 16G
- Apple's Mac address table: 4K
- Traffic control: IEEE 802.3x full-duplex flow control
PoE:
- PoE port: 4 10/100/1000Base-TX ports
- PoE standard: IEE802.3af, per port 12.5W
- Pin assignment: V+ (RJ45 Pin 4, 5), V- (RJ45 Pin 7, 8)

Features:

Conforms to IEEE802.3, IEEE 802.3u, IEEE802.3af
Provides eight 10/100/1000Base-TX ports
Provides 4 PoE injector and build in AC power
High back-plane bandwidth 10Gbps
IEEE802.3x flow control
Surge protection for power port and data ports
EMI standards complies with FCC, CE class B
