DVB-T2 TV Receiver with USB and RF Modulator

DVB-T2 TV Receiver with USB and RF Modulator

Get Latest Price

Payment Type:: Telegraphic Transfer (TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer (TT,T/T)

Product Description

Features:

Fully compliant with DVB-T2/DVB-T standard
Support MPEG-2, MPEG-4, H.264 decoder
Terrestial receiver standard: EN 302755/300 744 compliant
Frequency range: VHF-H 174~230MHz, UHF 470~860MHz
1,080p/1,080i/720p/576p/480p/576i/480i output supported
Auto and manually scan all available TV and radio channels
HDMI®1.3 interface
Aspect ratio: 16:9 and 4:3
Supports teletext (VBI or OSD)
Multi-language OSD and subtitle available
USB2.0 support PVR, time-shift, playback and softwareupgrade
Support external HDD via USB, power wanted if necessary
7-day EPG function
Time-shift function
Maximum 1,000 channels
Parental lock
Multiple PLP

Modulator features:

Standard EN300744
FFT mode: 2K, 8K
Bandwidth: 6M, 7M, 8M
Constellation: QPSK, 16QAM, 64QAM
Guard interval: 1/4, 1/8, 1/16, 1/32
FEC: 1/2, 2/3, 3/4, 5/6, 7/8
MER 42dB
RF frequency: 30~960MHz, 1kHz step
RF out: 2 x RF COFDM DVB-T out (2 carriers combinedoutput)
Double output bandwidth
RF output level: -30~ -10dbm (81~97 dbV), 0.1db step
Size of the machine: 2,020 x 115 x 38mm

Accessories:

Remote control
User's manual
RCA cable
Adapter (12V/1.5A)

Loading:

20ft GP: 6,500 pieces
40ft GP: 13,000 pieces
40ft HQ: 15,500 pieces

Fully compliant with DVB-T2/DVB-T standard

Support MPEG-2, MPEG-4, H.264 decoder

Terrestial receiver standard: EN 302755/300 744 compliant

Frequency range: VHF-H 174~230MHz, UHF 470~860MHz

1,080p/1,080i/720p/576p/480p/576i/480i output supported

Auto and manually scan all available TV and radio channels

HDMI®1.3 interface

Aspect ratio: 16:9 and 4:3

Supports teletext (VBI or OSD)

Multi-language OSD and subtitle available

USB2.0 support PVR, time-shift, playback and softwareupgrade

Support external HDD via USB, power wanted if necessary

7-day EPG function

Time-shift function

Maximum 1,000 channels

Parental lock

Multiple PLP

Standard EN300744

FFT mode: 2K, 8K

Bandwidth: 6M, 7M, 8M

Constellation: QPSK, 16QAM, 64QAM

Guard interval: 1/4, 1/8, 1/16, 1/32

FEC: 1/2, 2/3, 3/4, 5/6, 7/8

MER 42dB

RF frequency: 30~960MHz, 1kHz step

RF out: 2 x RF COFDM DVB-T out (2 carriers combinedoutput)

Double output bandwidth

RF output level: -30~ -10dbm (81~97 dbV), 0.1db step

Size of the machine: 2,020 x 115 x 38mm

Remote control

User's manual

RCA cable

Adapter (12V/1.5A)

20ft GP: 6,500 pieces

40ft GP: 13,000 pieces

40ft HQ: 15,500 pieces
