Power Video Balun with 8CH Power Video, 48V DC/2A Power Supply

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T or L/C at Sight, Western Union

Product Description

Channel: 8CH

PoE standard: IEEE802.3af/IEEE802.3 at

PoE specs: port: 15.4W/25.5WIEEE802.3 af/at power budget: 96W

PoE type: end -span 1/2 (+), 3/6 (-), mid-span 4/5 (+), 7/8 (-)

Network port: PoE ports: 1/4/8

Connector: RJ4S

Network: 10/100M

Auto-sensing

Cables: UTP Cat5e cable or above

PoE distance: 100m

Standard: IEEE802.3 i 10Base-T IEEE802.3 u 100Base-TX, IEEE802.3 x flow control

IEEE802.3 af/at power over Ethernet

Performance: store-and-forward

Packet forwarding rate: 0.6Mpps (5ã/1.2Mpps (9ã backplane bandwidth rate: 0.8G (5 ports)/1.6G (9 ports)

Type: 10/100Mbps auto-negotiation and auto MDI-MDI -X

Buffer memory: 96KB

Address database table size: 3,000 Mac Address

Network latency: less than 20us for 64 byte frames in store-and-forward mode

Protection: IEC 61000-4-2ESD ±15kV (air), ±8kV (constancy) 8/20us 24A 12A

Safety: CE/LVD CE Class B FCC part 15, class B C-Tick

Operating temperature:

No condensing: less than 5W

Power supply: 48V DC/2A

Dimensions: 117*105*28mm

Weight: 1.22kg

Support PoE power up to 15.4W for each PoE ports

Auto-detect powered device (PD)

Safe and reliable power to most of PoE end device

Plug-and-play function no configuration required

Easy network construction by PoE function

Easy installation with no configuration required

Working temperature: -10-55ºC

Storage temperature: -20-70°C, 10-90% RH working humidity
