WCDMA Module, Supports 7.2Mbps Downlink Speed and 5.76Mbps Uplink Speed SIM5218
  • WCDMA Module, Supports 7.2Mbps Downlink Speed and 5.76Mbps Uplink Speed SIM5218
  • WCDMA Module, Supports 7.2Mbps Downlink Speed and 5.76Mbps Uplink Speed SIM5218
WCDMA Module, Supports 7.2Mbps Downlink Speed and 5.76Mbps Uplink Speed SIM5218
WCDMA Module, Supports 7.2Mbps Downlink Speed and 5.76Mbps Uplink Speed SIM5218
WCDMA Module, Supports 7.2Mbps Downlink Speed and 5.76Mbps Uplink Speed SIM5218
WCDMA Module, Supports 7.2Mbps Downlink Speed and 5.76Mbps Uplink Speed SIM5218

WCDMA Module, Supports 7.2Mbps Downlink Speed and 5.76Mbps Uplink Speed SIM5218

Get Latest Price
Payment Type:
T/T or Western Union
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: T/T or Western Union
Product Description
Product Description
  • General features:
    • SIM5218A: Tri-band UMTS/HSPA 850/1,900/2,100MHz
    • SIM5218E :Tri-band UMTS/HSPA 900/1,900/2,100MHz
    • SIM5218J: Tri-band UMTS/HSPA 800/1,900/2,100MHz
    • SIM5218A/E/J: Quad-band GSM/GPRS/EDGE 850/900/1,800/1,900MHz
    • Video call with camera sensor interface
    • WCDMA: diversity
    • HSDPA: 7.2Mbps
    • HSUPA: 5.76Mbps
    • GPRS multi-slot class 12
    • EDGE multi-slot Class 12
    • Output power:
      • UMTS 850/1,900/2,100: 0.25W
      • GSM 850/900: 2W
      • DCS 1,800/PCS1,900: 1W
    • Control via AT commands
    • Supply voltage range: 3.4 to 4.2V
    • Dimensions: 58 x 26 x 4.5mm
    • Weight: 15g
    • Operating temperature: -30 to +80℃
    • Extended temperature: -40 to +85°C
  • Specifications:
    • HSDPA maximum 7.2Mbps (DL), UE category: 4, 6, 8, 12
    • HSUPA maximum 5.76Mbps (UL)
    • HSUPA + HSDPA maximum 2.0Mbps (UL) + 3.6Mbps (DL)
    • UMTS maximum 384kbps (DL), maximum 384kbps (UL)
    • EDGE class maximum 236.8kbps (DL), maximum 118kbps (UL)
    • GPRS maximum 85.6kbps (DL), maximum 42.8kbps (UL)
    • CSD GSM data rate 14.4kbps, UMTS date rate 57.6kbps
    • Multi-PDP connect application
    • GPS/location:
      • CELL assistant location (no GPS)
      • A-GPS mode: MS-based, MS-assisted
      • Standalone GPS
      • Qualcomm XTRA GPS mode
    • Network identity and time zone:
      • Support on GSM and WCDMA
    • Video call:
      • DTMF on H245
      • Support standard WCDMA 64kbps (CS) video call
    • SMS:
      • Point to point MO and MT
      • Text and PDU mode
    • Voice:
      • Voice codec HR, FR, EFR, AMR
      • DTMF
  • Other features:
    • USB drive for Linux 2.6.16/Google's Android
    • Firmware update via USB
    • MMS, TCP/IP, FTP/FTPS/HTTP/HTTPS/SMTP/POP3, FOTA
    • Jamming detection support
    • Interfaces
    • Embedded SIM card (option)
    • USB2.0 high-speed
    • UART, USIM
    • Audio: 2 microphones, 3 speakers
    • Camera interface
    • SD card interface
    • 12C interface
    • GPI
  • SIM5218A: Tri-band UMTS/HSPA 850/1,900/2,100MHz
  • SIM5218E :Tri-band UMTS/HSPA 900/1,900/2,100MHz
  • SIM5218J: Tri-band UMTS/HSPA 800/1,900/2,100MHz
  • SIM5218A/E/J: Quad-band GSM/GPRS/EDGE 850/900/1,800/1,900MHz
  • Video call with camera sensor interface
  • WCDMA: diversity
  • HSDPA: 7.2Mbps
  • HSUPA: 5.76Mbps
  • GPRS multi-slot class 12
  • EDGE multi-slot Class 12
  • Output power:
    • UMTS 850/1,900/2,100: 0.25W
    • GSM 850/900: 2W
    • DCS 1,800/PCS1,900: 1W
  • Control via AT commands
  • Supply voltage range: 3.4 to 4.2V
  • Dimensions: 58 x 26 x 4.5mm
  • Weight: 15g
  • Operating temperature: -30 to +80℃
  • Extended temperature: -40 to +85°C
  • UMTS 850/1,900/2,100: 0.25W
  • GSM 850/900: 2W
  • DCS 1,800/PCS1,900: 1W
  • HSDPA maximum 7.2Mbps (DL), UE category: 4, 6, 8, 12
  • HSUPA maximum 5.76Mbps (UL)
  • HSUPA + HSDPA maximum 2.0Mbps (UL) + 3.6Mbps (DL)
  • UMTS maximum 384kbps (DL), maximum 384kbps (UL)
  • EDGE class maximum 236.8kbps (DL), maximum 118kbps (UL)
  • GPRS maximum 85.6kbps (DL), maximum 42.8kbps (UL)
  • CSD GSM data rate 14.4kbps, UMTS date rate 57.6kbps
  • Multi-PDP connect application
  • GPS/location:
    • CELL assistant location (no GPS)
    • A-GPS mode: MS-based, MS-assisted
    • Standalone GPS
    • Qualcomm XTRA GPS mode
  • Network identity and time zone:
    • Support on GSM and WCDMA
  • Video call:
    • DTMF on H245
    • Support standard WCDMA 64kbps (CS) video call
  • SMS:
    • Point to point MO and MT
    • Text and PDU mode
  • Voice:
    • Voice codec HR, FR, EFR, AMR
    • DTMF
  • CELL assistant location (no GPS)
  • A-GPS mode: MS-based, MS-assisted
  • Standalone GPS
  • Qualcomm XTRA GPS mode
  • Support on GSM and WCDMA
  • DTMF on H245
  • Support standard WCDMA 64kbps (CS) video call
  • Point to point MO and MT
  • Text and PDU mode
  • Voice codec HR, FR, EFR, AMR
  • DTMF
  • USB drive for Linux 2.6.16/Google's Android
  • Firmware update via USB
  • MMS, TCP/IP, FTP/FTPS/HTTP/HTTPS/SMTP/POP3, FOTA
  • Jamming detection support
  • Interfaces
  • Embedded SIM card (option)
  • USB2.0 high-speed
  • UART, USIM
  • Audio: 2 microphones, 3 speakers
  • Camera interface
  • SD card interface
  • 12C interface
  • GPI
