HDMI Switch Splitter, Supports Highest Video Resolution 1080p

HDMI Switch Splitter, Supports Highest Video Resolution 1080p

Get Latest Price

Payment Type:: Telegraphic Transfer in Advance (Advance TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

This 4X4 matrix HDMI switch splitter by cat5e/6 offers unprecedented flexibility and convenience by routing high definition audio/video from any of four HDMI video sources to any of 4 displays over HDMI cable or 4 remote displays over inexpensive, standard CAT5e/6 cable. It eliminates the need to disconnect and reconnect sources to a display equipped with one input

Four receivers work with the switch splitter as a full functional module. Full high-resolution HDTV signals are supported up to a resolution of 1080p over HDMI cable 15m or at a maximum distance of 40M over two pieces of CAT5e/6 cable. It works with HD-DVD players, TiVo systems, HT PCs, and satellite set-top boxes that connect to an HDMI display. Every source and display is accessible at all times by selecting it with an IR remote or through RS232 port

This product has many features that enable it to perform in a superior manner. Among those features you will find:

Allows any HDMI display to view any source at any time
Allows any source to be displayed on multiple displays at the same time
HDMI or DVI to HDMI cables are used to connect the inputs and the matrix output
Each output includes one HDMI output and UTP output over cat5e/6, but only one way is available at a time
Each UTP output is connected to a receiver
UTP output extends signal up to 40m for 1080p by CAT-6 cable
Each Input includes an infrared emitter, which is used to control the long-distance source device by remote control
Each display's inputs can be switched with the IR remote control or through RS232
Supports highest video resolution 1080p
Supports 225MHz/2.25Gbps per channel (6.75Gbps all channel) bandwidth
Supports 12bit per channel (36bit all channel) deep color
Supports HDCP
Supports uncompressed audio such as LPCM
Supports compressed audio such as DTS Digital, Dolby Digital （including DTS-HD and Dolby True HD）
Supports 3D all format, including 1080p@23.98/24Hz, 720p@59.94/60Hz/50Hz, bandwidth up to 225MHz

Allows any HDMI display to view any source at any time

Allows any source to be displayed on multiple displays at the same time

HDMI or DVI to HDMI cables are used to connect the inputs and the matrix output

Each output includes one HDMI output and UTP output over cat5e/6, but only one way is available at a time

Each UTP output is connected to a receiver

UTP output extends signal up to 40m for 1080p by CAT-6 cable

Each Input includes an infrared emitter, which is used to control the long-distance source device by remote control

Each display's inputs can be switched with the IR remote control or through RS232

Supports highest video resolution 1080p

Supports 225MHz/2.25Gbps per channel (6.75Gbps all channel) bandwidth

Supports 12bit per channel (36bit all channel) deep color

Supports HDCP

Supports uncompressed audio such as LPCM

Supports compressed audio such as DTS Digital, Dolby Digital （including DTS-HD and Dolby True HD）

Supports 3D all format, including 1080p@23.98/24Hz, 720p@59.94/60Hz/50Hz, bandwidth up to 225MHz
