IEC60335 IP Tester

IEC60335 IP tester

For checking the protection against water to prove the degrees of protection with the
Second characteristic numerals 1 "Protection against water drops" and 2 "Protection of a
Specimen in a position of tilt against water drops"


According to IEC 60034-5 / 1991-01 § 9.1 Table IV Fig. 3, IEC 60529 / 1989-11 § 14.1 Table VIII Fig. 3, IEC60598-1 / 1999-02 § 9.2.3, IEC 60947-1 / 1999-02 Ann. § C. 14.1,
EN 60335-1 / 1994-09 + A11 / 1995-05 § 15.1.1, EN 60950 / 1992-08 + mod. Up to A4 / 1997-03 Ann. T, VDE 0570 Part 1 / 1998-07 § 17.1.1E, VDE 0630 Part


Introduction:
Dripping water device is designed to meet the requirements of IEC 60529. The tester can accommodate one of three different size drip boxes - 500mm x 500mm, 700mm x 700mm, or 500mm x 1000mm. The flow rate of drips is set and monitored by a user friendly touch screen controller that sets the water pressure to the drip box. The drip box and the water system is fully enclosed and filtered to minimize clogging of any nozzles.
The instrument is supplied with a specimen turntable that rotates at 1 rpm. The base of the turntable is 500mm high. The turntable can be wheeled in and out from under the drip box for specimen loading and unloading. The height of the box is electronically adjustable up to a height of 2500mm or 2000mm above the base of the turntable. Test duration is 10 minutes for IPX1 and 2.5 minutes for each angle adjustment of IPX2. The time of test can be set on the controller so the test stops automatically.
Application:
For checking the protection against water to prove the degrees of protection with the second characteristic numerals 1 "Protection against water drops" and 2 "Protection of a specimen in a position of tilt against water drops"

Features:

1. All English Touch Screen Control;
2. Fully conform to IEC60529 IPX1 IPX2 Drip Box Test;
3. Stainless steel nozzles removable for cleaning or replacing;
4. Drip flow rate precisely controlled by controller and pump;
5. With filter to ensure clean water;
