Door Controller 800kg Holding Force Electromagnetic Lock Ko-203f

Fail Safe: Locked when energized, power-cut to open.
Face Plate: 205Lx35WX41H(mm)
Strike: 90Lx25Wx2H(mm)
Bolt 16mmDIA, stainless steel 16mm throw
Voltage: 12VDC
Start Current: 900mA
Standby Current: 100mA
Solid Bolt: Polishing housing, 800Kg Holding Force
Suitable For: Woodeng Door, Glass Door, Metal Door, Glass Door
Signal Output: Door status Output, NC/COM
Surface Temp: Low Temperature
Induction Distance: 8mm
Operating temp: -10~+55C(14~131F)
Operating Humidity: 0~90%(non-condensing)
Special Designed: Tested to 500000 cycles
Face place material: High Aluminum, Carrulous Line Finished
Weight: 0.7kg

Low Temperature, safe & Durable
Low Power, Environmental Protection
Special photoelectricity control, three steps current application
Long Life with 500000 Operations
MOV Provides Reverse Current Protection
Superior Strength Aluminium Alloy, Solid Stain-less Steel Bolt
Door status signal output contact(NC. COM)
Double protection for loading current
Auto-relock if no Action within 5 secs.
Certificate: CE&MA
Photoelectricity Control, Low Temperature,
The Low Current is Changed immediately;
When door frame doesn`t coincide with door leaf, door leaf against the bolt, then the electric bolt will start the low-power function to bring low temperature.
The Photoelectricity Control Technology, prevent the machanical defect.
