16CH NVR 1080P Standalone DVR NVR

16CH NVR Case,
Support Review+Recording+Forward+WEB Server;
DualCore 32Byte DSP+Linux,
11pcs Touch Key, 11pcs LED, 1pc IR, 8pcs Sata HDD interface; 1pc E-Sata, 2pcs USB,
1pc shuttle flying, 1pc 100M Network Interface, HDMI, VGA, Audio In&out,
RS232; AC220V; 1pc IO Extension Port(1*RS485, 16CH Alarm In, 1 Alarm Out);
Support 16CH 720P/9CH 1080P Recording, Support VM3000 Server Management:
Support Web/client software/Mobile client Remote control;
Case Size: 440mm*370mm*90mm, 6.5KGS



NoSpecification AST - 6816
1SystemEmbedded Linux system, dual-core DSP, watch dog, hard disk storage, HD Display
A8+DSP, 720MHz, 32M FLASH, 4G DDR3;
2Video Input HD IPC access, dual-stream for each IPC, Auto research/add/record/preview.
16ch 720p, 9ch 1080p


3

Video Output1 HDMI output, 1 VGA output, Support 1920× 1080, 1440× 900, 1366× 768, 1280× 1024, 1024× 768, 800× 600 resolution ratio
1/4/9/16 Real time preview
1/4 video playback


4

Video Features8pc SATA HDD, 3.5inch SATA II hard disk, 2TB/3TB rated capacity, video record
Local video playback, internet long-distance playback,
Video resolution ratio: 720P/1080P H. 264
Max frame rate: 400fps@720p, 225fps@1080p
Max code stream: 48Mbps

5
Voice Intercom1ch 3.5mm stereo input, connect pickup; 1ch 3.5mm stereo output, connect power amplifier. G. 711/AAC encoding and decoding standard.
6Internet PortRJ 45 Ethernet port, 10/100/1000M adaptive, 8 remote users access 1pc RS485
Support FTP /PPPOE /DHCP /DDNS /NTP /UPnP network agreements
7Peripheral Port 1pc 232 SPI, 2pc USB port
8Alarm Port16ch on/off input, alarm input, 3ch(1A@24VDC)output, 1ch encoding output
9Expansion Port11*button, 11*LED, 1*IR, 2pcs Fans port, 1pc IO
10Service FeaturesUC Video Surveillance Client, VM3000 Platform management,
11OthersAC 100~240 V(50/60Hz), ≤ 12W power dissipation
