28 Ports FTTH L2 L3 10g Optic Fiber Aggregation Switches

28 ports FTTH L2 L3 10g Optic Fiber Aggregation Switches

Physic:

1, Dimensions(HxWxD)44mm x 440mm x267mm
2. Weight4.5kg
3. InterfaceOptical ports: 10GE SFP+ slots
4. Optical ports: 1000BaseX SFP slots
5. Optical ports: 100Base FX
6. Console port: RS-232(RJ45 connector)
7. Power supplyRedundant dual inputs (AC or DC)
AC voltage range: 90 VAC to 264 VAC; 50 Hz or 60 Hz
DC voltage range: -36 V to -72 V
8. Power consumptionno more than 55w
9. Predicted MTBF65, 000 hrs (25° C)
10. Operating Temp. 0° C to 60° C
11. Storage Temp. -10° C to 70° C
12. Relative humidity5% to 90% (non-condensing)

Standard:
IEEE 802.3IEEE 802.3ad (Link Aggregation)
IEEE 802.3u IEEE 802.1D (STP)
IEEE 802.3z IEEE 802.1w (RSTP)
IEEE 802.3ab IEEE 802.1s (MSTP)
IEEE802.3-2005 Clause 58/59IEEE 802.1Q
IEEE 802.3ae IEEE 802.1p (CoS)
IEEE 802.3x (Flow Control)IEEE 802.1X (Security)
Administration Protocol
RFC 826 (ARP)RFC 2819 (Remote Network Monitoring MIB (group 1, 2, 3, 9))
RFC 1812 (IPv4)RFC 1757 (RMON (groups 1 2 3 and 9))
RFC 783 (TFTP)RFC 1157 (SNMP)
RFC 768 (UDP)RFC 1902 (SNMPv2)
RFC 791 (IP)RFC 1901 (Community based SNMPv2)
RFC 792 (ICMP)RFC 2271 SNMPv3 Architecture
RFC 793 (TCP)RFC 2573 (SNMPv3 Applications)
RFC 2474 (Diffserv)RFC 2576 (Coexistence between SNMP v1, v2c, v3)
RFC 2622 (Routing policy)RFC 1058 (RIPv1)
RFC2461 (Neighbor Discovery for IPv6)RFC 1723 (RIPv2)
RFC 2462 (IPv6 Stateless Address Auto configuration)RFC 2080 (RIPng)
RFC 2464 (Transmission of IPv6 over Ethernet)RFC 2466 (MIB for IP Version 6)
RFC 2131 (DHCP)RFC 854 (Telnet)
RFC 2362 (PIM-SM)RFC 896 (Congestion control in IP/TCP network)
RFC 2267 (Network Ingress Filtering)RFC 925 (Multi-LAN ARP/Proxy ARP)
RFC 1156 (TCP/IP MIB)RFC 1122 (Requirements for Internet Hosts)
RFC 1212 (Concise MIB definitions)RFC 2597 (Assured Forwarding PHB group (partial support))
RFC 1213 (MIB for Network Management of
TCP/IP based internets (MIB II))RFC 2865 (Remote Authentication Dial In User Service)
RFC 2618 (Radius Authentication Client MIB)RFC 2869bis (Radius Support for Extensible Authentication
RFC 2620 (Radius Accounting MIB)RFC 3046 (DHCP/BootP Relay)
RFC2765 (Stateless IP/ICMP
Translation Algorithm)
