Cofdm Wireless Mobile Video Transmitter

Get Latest Price

Min. Order:: 1 Piece/Pieces

Min. Order:: 1 Piece/Pieces

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Basic Info.

Model NO.

MV2000TBHF/264

Oscillator Circuit

LC or Crystal Oscillator

Transport Package

Carton

Specification

SGS

Trademark

ALLTECH

Origin

Shenzhen, China

Production Capacity

5000pieces/Year

Product Description

Functions & Features:
N ABS/AES encryption
N Working frequency directly adjustable on panel
N Working bandwidth adjustable range upto 200MHz
N COFDM modulation (QPSK/16QAM)
N CVBS composite video input
N Left/right channel audio and unbalanced stereo input
N Video input PAL/NTSC optional (default as PAL)
N Transmitter power output adjustable
Cofdm Wireless Mobile Video Transmitter

Power Supply
Working voltage V		DC12V~DC16V
Working current A		≤2.8A@DC12.5V
Single battery capacity		14.8V/10.0AH
Video Transmission
Frequency output range		300MHz~450MHz,560~760MHz or user customized
RF bandwidth MHz		2MHz (fixed)
Power output		21~36dBm adjustable with 1dB step
C/N		≥28dB@32dBm
SHG		>52dBc
Encryption		AES/ALLTECH Basic scrambling
Modulation		COFDM
Constellation		QPSK,16QAM,64QAM optional QPSK/16QAM/64QAM @ 6/7/8MHz
FEC		1/2,2/3,3/4,5/6,7/8 optional
Carrier		2K
GUI	1/4, 1/8, 1/16, 1/32 optional
Video encoding	H.264
Video input level	1~1.2Vp-p@75Ω
Video input format	PAL/NTSC
Video resolution	720x576(PAL) 720x480(NTSC)
Video white bar amplitude mV	650~720mV
Video synchronous amplitude mV	260~275mV
Video amplitude-frequency characteristic dB	0~4.8MHz		-0.5~1.5
	5.5MHz		-4.0~1.5
Audio input	Left/right channel, stereo
RS232 control interface	Standard RS232 level, 9600, 8, N, 1
RS232 data interface	Standard RS232 level, support 1200~115200
Environment
Protect standard		IP66, dustproof and rainproof
Working temperature		-25°C~55°C
Storage temperature		-40°C~70°C
Appearance
Dimension		238mm×140mm×75mm
Weight		2.5kg
