Three-Axis Motion Controller with Human-Computer Interface All in One

JMDM-1830 Three-axis motion controller human-computer interface all in one
Introduction
1.JMDM-1830 is industrial grade three axis linkage controller and human-computer interface all in one,with strong anti-jamming ability, strong function, stable and reliable, widely used for controlling various dispensing machine, welding machine, machine hand grasping the material requirements of multi angle, multi direction, high precision, high speed.After years of large-scale industrial application of mature, JMDM-1830 has stable and reliable, high performance price ratio and excellent performance has greatly improved the production efficiency and economic benefit of the customer.
1).Performance of hardware and software
The hardware adopts high performance , industrial grade of imports singlechip, motion control dedicated chip and spare parts, system clock chip, professional stability,anti-interference circuit design, software using C language or assembly language programming, with good scalability,can realize many functions.
2).Appearance:Compact shell, parameters can be set through the membrane touch switch online LCD screen human-computer interaction interface, can be used to realize high precision, high speed positioning, timing, speed control, analog signal input and output control.
3).Compared with PLC and text display:PLC and text display JMDM-1830 industrial grade three axis linkage controller interface integrated machine function and can completely replace the various domestic and foreign brands, and one machine appearance is more compact, stable performance and more powerful, more high, price is higher.
2.Multifunctional combined products
JM1830 have basic type and multiple extended pattern products, can be customized according to customer's requirements.The following details:
Basic model:With 10 channels photoelectric isolation digital quantity input,NPN input form,the input current is 10ma,There are two channels can use the interrupt source,8 channels photoelectric isolation digital output, open collector output form, the maximum output current is 1A.Can control cylinder, solenoid valves, relays, etc., output frequency can reach 20KHZ;Can control 3 channel step or serer motor as motion control, pulse frequency is 200KHZ, max can be 400KHZ.
DA extension type:On basic type, more than 1 channel 12 bits high speed and high precision DA(analoy quantity) output, output range is 0V-10V.Stable and reliable, and conversion speed more quick, can be used to control frequency converter, proportional valve, welding current, etc.The extension products need to customize.
AD extension type:On basic type, more than 8 channels 12 bits high speed and high precision AD (analog quantity)input, but less 2 channels digital quantity input.Can be used in the inspection of analog control, such as voltage, current, temperature, humidity, pressure and so on the detection and control of analog signals;The extension products need to customize.
Applications
1).Currently has been widely used in step and servo motor three-axis association  as motion control occasions.
2).Used for various control systems within 18 points ,can be controlled pneumatic cylinder, solenoid valve, relay, step and servo motor, proportional valve control and transducer control,etc.High speed, high precision analog input/output, digital quantity input and output occasions.
4.Successful application case
Successful application case in all over the country provinces and cities, Hong Kong, Macao and Taiwan regions,are succeed and widely used in rubber machine, welding machine, machine hand grasping the material requirements of multi angle, multi direction, high precision, high speed motion control applications,stable and reliable running, successfully survived the bad industrial environment of strong electromagnetic, high-frequency interference test, with high cost performance has won the broad customers trust, and sells in distant markets overseas.
