Fiber Optic Video Signal Converters CCTV Video Converter

Product specifications

Product characteristics

64 Channel digital video and data ,audio transfer over
single fiber
Mini body, ultra slim design
8 Bit uncompressed video transmission
24 bit audio signal sampling

NTSC,PAL,SECAM CCTV
Support RS485,RS232 data protocol
No EMI, RFI, Cross Talk, and Ground Loop
Surface Mount Technology
Standalone or rack mount

Application

CCTV system
Intelligent transportation system(ITS)
TV medical treatment
Long-distance Muti-media Schooling, Campus monitoring
Long-distance broadcast television transmission system
Tele-Communication System

 Military Tele-Com projects

Specification

1.Power

Stand-alone: 220VAC or -48VDC

2.Video

 Channel:4  ormat: PAL/NTSC/SECAM ignal: 1Vp-p, 75Ω

Digitization: 8bits/10bits digital encoding, 16M sampling

Bandwidth: 8MHz DG: <1 DP: <1°  SNR: >65dB Connector: BNC

3.Audio

Connector: Terminal Blocks
Audio input / output impedance :600Ω(Balance/ unbalance)
Audio input / output voltage :2Vp-p ( typical value)
Audio input / output level :0dBm ( typical value)
Video bandwidth:10HZ~12KHZ
Audio digital encoded bandwidth :24bit
Audio signal-to-noise ratio: S/N≥95dB (weighted)

4.Data

Connector: Terminal Blocks
Encoded type : RS485 / RS422 / RS232 / Manchester
Data rate : 0 - 400Kbps
BER: ≤10-9

5.Telecom

Connector: RJ11
Bandwidth :8KHZ
Features:Support call-showing function ;support H-F
Operating mode : Point to point hotline mode / FXS-FXO

6.Ethernet

Connector:RJ45
Support mode : Half duplex or Full duplex
Standards:IEEE802.3
Data rate : 10M / 100Mbps
Bandwidth: 25M

Warranty policy

Vedio convertor is three year warranty as following::

The factory warranty period is three years from date of delivering goods.

The buyer should return the goods if it donot working well within 3 month,the seller will give money back. Or seller send new item to replace bad item,all transportation cost be paid by seller.

after 3 to 6 monthes,repair free,half transportation cost for both,pass for 6month the cost we need discuss.
