LED Video Wall P25

 P25 Outdoor Full Color LED Screen Parameter

No.TypeFull Color
1. Pixel Configuration: 1R+1G+1B
2. LED Type: DIP546
3. Module Resolution: 16pixels(H)×8pixels(W)
4. Module Dimension: 160mm(H)×320mm(W)×160mm(L)
5. Power Consumption(average): 400w/ m2
6. Power Consumption(max): 650 w/ m2
7. Density: 2500pixels/m2
8. Brightness: >5500 nits
9. Color: 16.7 M
10. Brightness Control: Manual/Auto
11. Gray Scale Rectification: rrectification
12. Picture Regulation: Contrast/Chroma regulation/Module brightness regulation
13. Drive Mode: Static
14. Refresh Rate: 1080HZ
15. Control Mode: Synchronization control
16. Video Interface: S-Video, VGA, DVI etc.
17. Life Time: 100,000 hours
18. Mean Time To Failure: >10,000 hours
19. Blind LED: None
20. Temperature: -35°C~+55°C
21. Relative Humidity: 10%-95%RH
22. Display Flatness: The display:±1mm Gap between modules:1mm
23. Display Information: Text, Video and Picture etc.
24. Voltage: 220V±10%,380V±10%
25. Communication Distance: <20km
26. Waterproof: IP65
