IGBT Snubber Capacitors (MPB-6.3UF)

Features:
1. High Peak&RMS Current Capability.
2. Mount Directly to the IGBT Module.
3. Low Inductance4. Low Loss Polyprop.
5. Self Healing.
6. Flame Retardant plastic case and epoxy resin(UL-Class 94V-0).
Applications:
Snubber, Energy conversion and control in power semiconductor circuits, IGBT modules protection and SMPS protection circuits, high voltage, high current and high pulse applications.

Specification:
1. Operating Temperature: -40ºC to +85 ºC.
2. Capacitance Range: 0.047UF to 6.3UF.
3. Capacitance Tolerance: J=+, - 5%, K=+, -10%, M=+, -20%.
4. Rated Voltage(RV): 700, 850, 1000, 1200, 1500, 2000, 2500, 3000VDC.
5. Dissipation Factor(DF): C≤ 1.0UF DF=0.05% Max, C>1.0UF DF=0.06% max.
6. Testing Voltage(TV) at 25ºC 160% of RV Applied for 10sec/200% of RV applied for 2 sec.
