Wireless Router Bridge WiFi Bridge Vap 11n

Wireless router repeater VAP11N Datasheet
VAP11N is a professional 150M Mini WiFi Bridge, together with WiFi Repeater function, that is elaborately developed by HouTian Network, the original creation D/A temperature compensated auto frequency control technology(TAFC), it solved the common failing of the traditional wifi router or wifi products that easily drop the network, make sure the lasting stability to ensure that the WiFi signal is not dropped. It is based on IEEE 802.11N standard, can extend WiFi Network range, provides the stable transmission up to 150Mbps, also is compatible with IEEE 802.11B and IEEE 802.11G standard.

VAP11N is a safe environmental WiFi signal Repeater. In WiFi bridge and repeater mode, VAP11N can double extend the existing WiFi signal range, also can make sure the safey of WiFi signal. The work theory is: On the edge of the original WiFi hotspot signal coverage, put a VAP11N under "WiFi Repeater mode", VAP11N will extend the weak WiFi signal receive to normal and safe strength and after optimization and error correction processing to reach the double extension of WiFi signal range under the premise security. It is different from traditional WiFi Signal amplifer— It just amplifies the signal and ignore the WiFi security.

VAP11N provides three kinds of power supply methods, omits the worries of carrying a lot of power adapters, usage is more flexible; Plug and play, meet the flexible network solutions. VAP11N has practical function, superior performance, is easy for management and provides multiple safe protective measure, can protect the security of user's WiFi network.

Enviromental, Safey, Portable, Mini
Traditional intelligent WiFi Bridge, together with WiFi repeater function.
WiFi intelligent bridge mode, it supports WiFi hotspot scan automatically and WiFi hotspot memory function.
The best partner of STB, IPTV, Sky Box, X-BOX, IP camera and SLR camera.
Support WEB remote firmware upgrade, can get the latest firmware free.
Support local WEB management, Chinese and English configuration interface.
Adopt the original creation D/A temperature compensated auto frequency control technology(TAFC), make sure the lasting stability to ensure that the WiFi signal is not dropped
Original creation VDNS virtual domain configuration technology to solve the user's trouble of configuration.
Support connecting more than 20pcs WiFi terminal at the same time.
Support WPA-PSK/WPA2-PSK, 64/128/WEP security mechanism.
Support 802.11n WiFi transmission protocol, 150Mbps rate of transmission.
The transmission distance (without obstacle): 100m
Wide voltage (DC5V-15V), Low power consumption (
Three Parallel DC power connector DC power interface (ACPI): DC2.5 power hole, DC2.0 power plug, USB interface ( for electricity use), it is convenient for customer to share power supply with devices.

In software operation, HouTian Network insists simple and humanized design, abandons the the complicate parameters and operations of traditional wifi router, also supports two configure mode IE browser configuration and PC dedicated software configuration (no need IP connection), the procedure is so clear and concise, without redundancy, greatly facilitates the use of different levels of users.

Hardware Spec
Protocol Standard
IEEE 802.11g. IEEE 802.11b. IEEE 802.11n
Rate of transmission
150Mbps
Interface
1 DC2.0 power hole;
1 dedicated two in one power supply cable, with a set of power
Supply and a set of 10/100M adaptive Ethernet cable
Button
Reset button (Long press)
LED
Status instruction:
Ethernet cable status Light
WiFi status Light
Antenna
Built-in Intelligent Omnidirectional antenna
Size
59.5mm x 35mm x 11.5mm(L x W x H)
