Satlink Ws6909 DVB-S&DVB-T Combo Satellite Finder Ws6906

DVB-T COFDM Demodulated Frequency range: 46-870MHz Level range: 40-110dBuV Input Resistance: 75ohm Demodulation: QPSK, 16QAM, 64QAM Test: BER, C/N, FEC Signal Quality and Strength Multi-Channel Simultaneous Measurement Auto Full Frequency Scan Auto scan of frequency selected Power supply at RFIN: 5V/12V/15V/18V/24V*(100mA)

DVB-S Input Frequency range: 950-2150MHz Input Level: -65dBm-25dBm Input Resistance: 75ohm Symbol rate: 2Msps-45Msps Test: BER, C/N, FEC Signal Quality and Strength Auto search: NIT Search, Manul Search DisEqC, 22K Supported LNB power supply: H + 18V + 13V 400Ma

OTHER 8.4V/3000mAh Lion battery Power adapter input: AC 90V-240V/50Hz Power adapter output: DC 12V/1.5A Working time: 4-6 hours (full charge) Charging time: 5 hours from flat Car charger supplied Dimension: 155 X 95 X 45mm Net weight: 0.6kg

For the first time in a economical digital meter, you are now able to view the actual channel on the screen of the meter. Now you can quickly and accurately align the satellite AND you can instantly check the stability of the channel right on the screen of the meter. Transponders, Frequency, Symbol Rate, Polarity, and other settings can be modified by the user. There is never a need to send your meter in for a upgrade. Meter never needs to be returned for re-calibration due to the unique calibration system built in to the meter. Each time the meter boots up it automatically calibrates for optimum performance so you can align each install with confidence.
