6 Channel Mixing Console with 4 Balance/Unbalanced Mono Line Input

FEATURES

*8 Balance/unbalanced mono line input.
* 8 low noise high headroom XLR mic input.
* 4 pairs of balanced/unbalanced stereo line inputs with +4/-10 input gain/sensitivity selector.
* ALT3-4 extra stereo Aux.
*PEF/SOLO and Mute/ALT3-4 on all channels.


SPEC.
*THD:0.025%(THD+N)
*Frequency response: 10Hz-60kHz (+3dB,-3dB),20Hz-20KHz(+0dB,-0dB)
*S/N rate (A weight): 80dB.
*cross talk: -70dB (1KHz and 10KHz)
*MIC input sensitivity: -68dB(normal output :+4dB)
*Line input sensitivity:50dB(normal output: +4dB)
*Stereo input sensitivity:-12dB(Normal output :+4dB)
*Gain control :50dB
*EQ control:±15dB (High:12KHz;Mid:2.5KHz;Low:80KHz
*MAX out :+22dBm
*Impedance: MIC input impedance 3KΩ
*Other input impedance: 10KΩ
*Out impedance: 120Ω
*Headphone max out: 50MW/8Ω
*DC global phantom power:+48V
*Noise:-128DbM (A weight, Rs=150Ω
