Digital Display Double Mitre Saw in Heavy Duty

SG-383A-B Digital Display Double Mitre Saw in heavy duty

Primarily used for cutting aluminum alloy window and curtain wall profile, may also used for cutting plastic profile. Adopted the hard quality alloy saw blades, the external diameter can reach 20, the linear speed is high, the accuracy of processing is high. The left and right sawing units can cut profiles simultaneously or separately. Sawing units can be adjusted to the needed angle between 90° -45° . The worktable of this aluminium cutting machine can rotate in the range of 0° -45° . This cutting machine equipped with digital display device, the size positioning is accurate.

Main Technique Parameter
1. Saw cutting length...450-4500mm
2. Saw cutting (W× H)...215× 150mm
...240× 135mm
3. Main motor power...2.2Kw× 2
4. Main motor rotation speed...2840r/min
5. Saw blade dimension...Φ 500× Φ 30× 120T
6. Saw blade swing angle range...90° -45°
7. Worktable swing angle range...0° -45°
8. Saw blade feeding speed...0-3m/min
9. Saw blade returning speed...2-3m/min
10. Working air pressure...0.6-0.8Mpa
11. Working voltage...380V
12. Overall dimension (L× W× H)...5850X1380X1360mm
13. Weight...1600Kg
