4chs 960P HD MDVR With 7.0" Monitor From Wardmay Ltd
The vehicle Dvr Recorder belongs to the market segment of the traditional embedded DVR. Digital Video Recorder is an emerging special product developed with the application of digital video and audio coding technology in vehicles. Compared with 6 In 1 Hd Dvr, It uses an embedded processor and embedded operating system, combining the latest H.264 audio and video compression/decompression technology, GPS global positioning technology, 3G wireless communication technology, USB communication technology, and advanced vehicle power management technology in the IT field. GIS geographic information technology, suitable for 24-hour monitoring of all types of vehicles. It can carry out audio and video synchronous recording, global positioning, wireless audio and video real-time transmission, and at the same time, a variety of interfaces are reserved on the host, which can be connected with on-board devices such as car display, IC card vehicle, signal priority control system, passenger flow statistics system, etc. Widely used in public transportation, long-distance passenger transport, school buses, engineering vehicles, container trucks, tourist buses, logistics and freight, police law enforcement vehicles, trains, subways, ships, aircraft and other mobile vehicles. CCTV Camera which use in car, it need to use with MDVR , so it can insure security of driving. Car Security Camera is neccessory.
Specification
| Model No. | WDM-3G8504A | ||
| Video compression | H.264 | ||
| Operate System | Linux | ||
| Solution | 4x960p/25fps H.264, HD DVR, Hisi3520D | ||
| Language | Chinese/English/Other(optional) | ||
| GUI | |||
| OSD | Character overlay function,support information image overlay such as time and date, vehicle ID, etc. | ||
| OSD interface | The system parameters can be set by the external display and remote control operation. | ||
| Video and Video System | |||
| Video input | 4chs composite video input | ||
| Video output | 1chs composite viedo output+ 1chs VGA 1.0Vp-p support 1ch full screen,4chs split screen | ||
| Preview function | 1ch, 4chs screen stitching preview, support manual / event trigger full screen display function | ||
| Video resolution | Support 960P, D1, HD1, CIF | ||
| Recording rate | PAL: 100 frames/s, CCIR625 line, 50 games | ||
| NTSC: 120 frames/s, CCIR525 line, 60 games; | |||
| CIF: 256Kbps ~ 1.5Mbps, multi-level image quality optional | |||
| HD1: 600Kbps ~ 2.5Mbps, multi-level image quality optional | |||
| D1: 800Kbps ~ 3Mbps, multi-level image quality optional | |||
| 720P: 1Mbps-4Mbps, multi-level image quality optional | |||
| Video mode | Default automatic recording, support for ignition recording, manual recording, alarm recording, etc. | ||
| Audio | |||
| Audio input | 1chs AV interface | ||
| Audio output | 1ch | ||
| Compression format | G7.62 compression format,rate8KB/S | ||
| Alarm input | 4-channel IO alarm input, pulse speed input; with alarm linkage function | ||
| Alarm output | 2chs switch output, linkage sound and light alarm, oil cut-off, etc. | ||
| Communication interface | 1 ch RS232, expandable credit card machine, oil quantity sensor, LED advertising screen, OBD, etc. | ||
| 1 ch 485 interface, expandable pan/tilt | |||
| SD Card | |||
| SD card | 1*SD card ,up to 256G, with a lock to protect them | ||
| Upgrade method | Support U disk upgrade, SD card upgrade, FTP remote automatic upgrade | ||
| Storage method | Proprietary bare disk storage: currently the industry's advanced storage | ||
| USB | Front USB interface, you can use U disk to upgrade backup data; backup video, support USB mouse | ||
| Video playback | |||
| Video search | Search video and video data by recording time, recording mode, etc. | ||
| Playback | Support 4 channels of synchronous playback, pause, fast forward, rewind | ||
| Support 2, 4, 8, 16 times speed fast forward or backward | |||
| Power and power consumption | |||
| Power management |
Adaptive wide-format power input with protection functions such as overload, undervoltage, short circuit, and reverse connection; Support timer switch, delay shutdown function. |
||
| Input voltage | DC: +9V ~ +36V | ||
| The output voltage | +12V/2.5A, +5V/2A | ||
| Power consumption | Normal working condition <5W | ||
| Working environment | |||
| temperature | -20°C to +70°C | ||
| humidity | 20% to 80% | ||
| Safety management | |||
| Password access | User password, administrator password management | ||
| Others | |||
| Size | 15CM(D)* 14.7CM(W)* 4CM(H)(reference size) | ||
| net weight | 1KG | ||
