Single Pole Drop Arm Turnstile for Access Control System

Single Pole Drop Arm Turnstile for Access Control System (YET-B652)
Drop Arm Turnstiles, Sliding Gate Turnstile, Tripod Barrier, Swing gate turnstile, Wing gate turnstile, Access Control Systems, Optical Turnstile, Half heitht turnstile, Full height turnstile
Single Pole Barrier
Fashion droparm turnstile
Material of case: Domestic standard SUS (304#)

Specification
1. Dimension: 1200*170*990mm
2. Length of stick: 300MM, optional range: 250-500MM
3. Weight: 90KG
4. Material of case: Domestic standard SUS (304#)
5. Power supply voltage: AC220± 10% V, 50Hz(AC110V is optional)
6. Drive Motor: DC brushed motors (24V)
7. Input interface: Electricity relay switch signal or 12V level signal, or 12V pulse signal with
8. Whose pulse width >100ms, drive electricity >10mA
9. Normal service life: 3 million times
10. Communication interface: RS485
11. Transit speed: 30-40 people/ minutes
12. Closing and opening time of stick: 1 second
13. When power on, 3 seconds needed for it to enter into passing status.
14. When there is breakdown, 10 seconds needed for its automatic return/reset.
15. Working environment: Indoor, outdoor (shelter)
16. Temperature: -10° C— — 50° C
17. Relative humility: ≤ 90%, no-condensation
Features:
1. Malfunction self-checking and alarm warning, ease of maintenance and installation
2. Operation method can be programmable
3. Anti-Pinch, stop when it detects movement in the passage.
4. Anti-rushing function: Auto lock if no valid signal is given
5. Doors can be adjusted into synchronization (only for double-locks)
6. Pass right will be cancelled if it is beyond the preset time
7. Normal close or normal open
8. Compatible with most access control systems
9. One direction or bi-direction control
10. Remote control by computer
11. Auto reset for time delay
12. Passable on power failure, meet the requirements of fire-fighting.
13. Sound and lights alarming: Including break-in and opposite direction intrusion, and so on.
14. Counting function (optional)
15. Speech output, human voice warning the right passing. (Optional)
