Mm to Sm Media Converter

Name: MM to SM media converter

Multi-mode to Singer-mode:
DTLM series equipment can be used for ATM or SDH Single mode to Multimode conversions.
Available in all type distances and fiber types, including the WDM. Converter supports standard
ATM/SDH/OC-3 speed from 155 - 622-1250 Mbit / s and higher
Overview:
DTLM series equipment can be used for
ATM or SDH Single mode to Multimode conversions.
Available in all type distances and fiber types, including the WDM. Converter supports standard
ATM/SDH/OC-3 speed from 155 - 622-1250Mbit / s and higher
Features:
· Supporting single fiber by double directions transmission;
· According to any agreement between different dates.
· Fulfilling medium convert between single-mode fiber and multi-mode fiber or extending fiber transmission distance, the wave length may be 850nm, 1310nm or 1550nm.
· Supporting medium convert between OC3 - OC12, OC24, STM-1, STM-4, STM-8 or ATM or just for extending transmission distance.
· The longest transmission distance of multi-mode is 2KM; The longest transmission distance of single-mode is 120KM.
· WDM single fiber versions are available
· As optical receiving and sending model with good optical character, electrical character, date transmits steady, and it can work for long time...
· The transmission of optical mode 155M is above 30db and optical mode 1.25G is above 25db.
· As it is manufactured by assembly line with advanced jointing, model works steady, date transmits stably, and its anti - interference is outstanding.


· Optical fiber interface: SC, ST, FC
· Optical fiber type:
Multi-mode: 50/125um, 62.5/125um, 100/140um, wave length: 850 or 1310nm
Single-mode: 8.3/125um, 8.7/125um, 9/125um, 10/125um, wave length: 1310 or 1550nm
· Transmission distance: Multi-mode with 2KM, single-mode up to 120KM.
· Transmission rate: 10/100Mbps, 155Mbps, 622 Mbps, 1000 Mbps, 1.25Gbps, 2.5Gbps
· Indicator light: It indicates power supply's condition, also suggests single-fiber and multi-fiber link condition.
· Power supply: Absolute construction: 1) input 100v ~ 260VAC 2) input 36V-72VDC, output 3W.
· Power: · Size: 26mm (H) * 70mm (W) * 94mm (D)
· Work temperature: 0 ~ 70 degree
· Storage temperature: -20 ~ 80 + degree
· Humidity: 5% ~ 90% without condensing
