Professional FTTH, Indoor/Outdoor Glass Optical Fiber/ Fiber Optic Cable

FTTH, indoor, outdoor glass optical fiber/fiber optic cable
1. Product Characteristics (Overall)
1) singlemode fiber size parameters ¦
Fiber Type ¦ ITU T G. 657A
Fiber Specification ¦ 62.5/125/245 μ M
Core Diameter ¦ 62.5 +/- 2.5 μ M
Core NonCircularity ¦ ≤ 5 %
Mode Field Diameter ¦ 8.6~9.5 +/- 0.4 μ M
Clad Diameter ¦ 125.0 +/- 0.7 μ M
Clad NonCircularity ¦ ≤ 1.0 %
Core/Clad Concentricity Error ¦ ≤ 0.5 μ M
Primary Coating Diameter ¦ 245 +/-10 μ M
Clad/coating Concentricity Error ¦ ≤ 12.5 μ M
Color Code ¦ 1. Blue 2. Orange 3. Green 4. Brown
2) Non-metallic strengthening¦
Total number of root ¦ 2 Root
Material ¦ FRP - Glass Fiber Reinforced Plastic Rods
Diameter ¦ 0.35 +/- 0.02 mm
3) Strengthening Messenger Wire ¦
Total number of root1 Root ¦ 1 Root
Material ¦ Phosphating steel wire
Diameter ¦ 1.20 +/- 0.05 mm
4) Outer Jacket ¦
Material ¦ LSZH Lowsmoke halogenfree flame retardant polyolefin
Color ¦ Black & White
Diameter ¦ 2.0× 6.1 +/- 0.20 mm
Marking ¦ Per Customer Request
5) Packaging ¦
Cable Net Weight ¦ 23.0 kg/km
Product Length ¦ 1640FT(500m)/Plywood Drum/Cardboard Carton
3280FT(1000m)/Plywood Drum/Cardboard Carton
6562FT(2000m)/Plywood Drum/Cardboard Carton
2. Optical Characteristics (Overall)
1) Singlemode fiber cutoff wavelength ¦ ≤ 1250 λ C/nm
2) Singlemode fiber cutoff wavelength ¦ ≤ 1260 λ C/nm
3) Maximum Attenuation @ 1310 nm ¦ ≤ 0.40 dB/km
4) Maximum Attenuation @ 1550 nm ¦ ≤ 0.30 dB/km
5) Dispersion Coefficient 1288~1339 nm ¦ |D ≤ 3.5 ps/nm· Km
6) Dispersion Coefficient 1271~1360 nm ¦ |D ≤ 5.3 ps/nm· Km
7) Dispersion Coefficient 1550 nm ¦ |D ≤ 18 ps/nm· Km
8) Zero dispersion Wavelength ¦ 1300~1322 nm
9) Zero dispersion slope ¦ ≤ 0.092 ps/nm² × Km
10) Light source continuity ¦ Continuous
3. Fiber Mechanics Characteristics
1) To allow the construction of shortermtensile force ¦ ≤ 200 N
2) runs allowed when used longterm tensile strength of ¦ ≤ 100 N
3) To allow the construction of shortterm flattening force ¦ ≤ 2200 N/100mm
4) Longterm pressure allowed when run using Chen Shuibian ¦ ≤ 1000 N/100mm
5) Static (working) minimum bend radius ¦ ≥ 30 mm
6) Dynamic (installation) minimum bend radius ¦ ≥ 60 mm
7) Storage Temperature Range ¦ 20 ~ +70 ° C
8) Install the temperature range ¦ 5 ~ +40 ° C
9) Operating temperature range ¦ 40 ~ +60 ° C
