OTDR Exfo Ftb-200V2

OTDR EXFO FTB-200v2 in stock!
The FTB-200 V2 delivers the best performance on the market for optical, Ethernet and SONET/SDH testing.

KEY FEATURES
Intel ATOM processor with Windows Embedded Standard for maximized productivity and unique versatility
Flexible connectivity with USB, mobile, Wi-Fi and Bluetooth capabilities
Compatible with 11 families of modules for multiple field testing applications
CWDM network characterization at eight wavelengths
40G and ROADM commissioning with an optical spectrum analyzer
Multiservice testing with a next-generation SONET/SDH analyzer
Fiber characterization and construction with OTDR, loss, dispersion and multitest modules
Business service activation with OTDR and Ethernet test modules
Carrier Ethernet testing from 10 Mbit/s to 10 Gbit/s
ONE PLATFORM, OVER 30 MODULES
Optimized for all phases of the network lifecycle, the FTB-200 v2 houses any of EXFO's FTB one- or two-slot modules to meet your evolving needs. Configure your platform by combining optical, transport and datacom modules to cover a wide range of applications. Offering power, speed and modularity in a compact format, the FTB-200 v2 is the perfect tool for the field.


ORDERING INFORMATION
FTB-7200D Multimode and Singlemode (ACCESS and LAN/WAN OTDR)
FTB-7200D-12CD-23B = Four-wavelength MM/SM OTDR module, 850/1300 nm (50/125 μ M and 62.5/125 μ M) and 1310/1550 nm (9/125 μ M)
FTB-7200D-12CD = Dual-wavelength MM OTDR module, 850/1300 nm (50/125 μ M and 62.5/125 μ M)
FTB-7200D-023B = Dual-wavelength SM OTDR module, 1310/1550 nm (9/125 μ M)
FTB-7300E Singlemode (FTTx-PON/MDU)
Dual-wavelength
FTB-7300E-023B = SM OTDR module, 1310/1550 nm (9/125 μ M)
FTB-7300E-034B = SM OTDR module, 1550/1625 nm (9/125 μ M)
Triple-wavelength
FTB-7300E-234B = SM OTDR module, 1310/1550/1625 nm (9/125 μ M)
FTB-7300E-236B = SM OTDR module, 1310/1490/1550 nm (9/125 μ M)
SM Live Port
FTB-7300E-023B-04B = SM and SM Live OTDR module, 1310/1550 and 1625 nm Live Port
FTB-7300E-023B-08B = SM and SM Live OTDR module, 1310/1550 and 1650 nm Live Port
FTB-7300E-000-04B = SM Live port OTDR module, 1625 nm Live port only
FTB-7400E Singlemode (METRO/CWDM)
Dual-wavelength
FTB-7400E-0023B = SM OTDR module, 1310/1550 nm (9/125 μ M)
Triple-wavelength
FTB-7400E-0234B = SM OTDR module, 1310/1550/1625 nm (9/125 μ M) a
Four-wavelength
FTB-7400E-2347B = SM OTDR module, 1310/1383/1550/1625 nm (9/125 μ M) a
FTB-7400E-CWS = CWDM SM OTDR module, 1470/1490/1510/1530 nm (9/125 μ M) a
FTB-7400E-CWCL = CWDM SM OTDR module, 1550/1570/1590/1610 nm (9/125 μ M)
FTB-7500E Singlemode (METRO/LONG-HAUL)
Dual-wavelength
FTB-7500E-0023B = SM OTDR module, 1310/1550 nm (9/125 μ M)
FTB-7500E-0034B = SM OTDR module, 1550/1625 nm (9/125 μ M)
FTB-7600E Singlemode (ULTRA-LONG-HAUL)
Dual-wavelength
FTB-7600E-0023B = SM OTDR module, 1310/1550 nm (9/125 μ M)
FTB-7600E-0034B = SM OTDR module, 1550/1625 nm (9/125 μ M)
Our main products as below:
1. FUSION SPLICER: Sumitomo (Type-81C/39/-66/); Fujikura (fsm-60S/60R); Fitel S178A; HSV-6000
2. OTDR: EXFO (FTB-1/AXS-110/AXS-100/ FTB-200/FTB-500); JDSU (MTS-2000/4000/6000/8000); YOKOGAWA (AQ7275)
3. POWER METER (PPM-350c, FPM-300, HSV300-P); LIGHT SOURCE (FLS-300, HSV300-L); VFL (FLS-241, HSV-321); Multi Loss tester (FOT-930, FOT-302)
4. Anritsu site master S331D, S331L, S331E, S332E.
5. Fiber cleaver (CT-30A/FC-6S), adapter, battery, electrode, connector, fiber tool kits
6. Fiber cable, patch cord, adapter, closure, pigtail, optical switch, patch panel, etc...
7. Maintainance and repair, calibration service for the EXFO, Sumitomo, Fujikura, Anritsu.
