1.55v Sg4 Sr66 377 Silver Oxide Button Cell
- Payment Type:
- L/C, T/T, D/P, Paypal, Money Gram, Western Union
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | China |
|---|---|
| Payment Type: | L/C, T/T, D/P, Paypal, Money Gram, Western Union |
Product Description
Product Description
SG4 SR66 377 Silver Oxide Button Cell
Nonimal Voltage: 1.55V
Diameter: 6.80mm
Height: 2.60mm
SG4 SR66 377 Silver Oxide Button Cell
N0MINAL VOLTAGE: 1.55 VOLT
APPROX. SERVICE CAPACITY: (A)25mAh (B)22mAh
APPROX. WEIGHT: 0.34 g
RATED AT 45, 000 OHMS LOAD TESTED AT 21° C WITHIN 30 DAYS OF MANUFACTURE.
SYSTEM: ZINC/ SILVER DIOXIDE, MANGANESE DIOXIDE.
ESTIMATED AVERAGE HOURS SERVICE AT 21° C
VOLTAGE DISCHARGE CURVE AT 21° C.
DISCHARGE SCHEDULE: 24 HRS/DAY.
1.6 V LOAD: 45, 000 OHMS. CUT-OFF VOLTAGE: 0.9V
1.5 V
1.4 V
1.3 V
1.2 V
1.1 V
1.0 V
0.9 V
0 96 192 288 384 480 576 672 768 864
HOURS OF SERVICE D80
SG4/SR626 SILVER CELL
. 6.75 ± 0.05mm
. 4.60 ± 0.10mm
2.25± 0.1mm
2.6 ± 0.1mm
Cathode Cap
Separator
Anode Manganese
Anode Can
Gasket
Cathode Zinc Plaster
(A)100% silve(B)60% silver r
Nonimal Voltage: 1.55V
Diameter: 6.80mm
Height: 2.60mm
SG4 SR66 377 Silver Oxide Button Cell
N0MINAL VOLTAGE: 1.55 VOLT
APPROX. SERVICE CAPACITY: (A)25mAh (B)22mAh
APPROX. WEIGHT: 0.34 g
RATED AT 45, 000 OHMS LOAD TESTED AT 21° C WITHIN 30 DAYS OF MANUFACTURE.
SYSTEM: ZINC/ SILVER DIOXIDE, MANGANESE DIOXIDE.
ESTIMATED AVERAGE HOURS SERVICE AT 21° C
VOLTAGE DISCHARGE CURVE AT 21° C.
DISCHARGE SCHEDULE: 24 HRS/DAY.
1.6 V LOAD: 45, 000 OHMS. CUT-OFF VOLTAGE: 0.9V
1.5 V
1.4 V
1.3 V
1.2 V
1.1 V
1.0 V
0.9 V
0 96 192 288 384 480 576 672 768 864
HOURS OF SERVICE D80
SG4/SR626 SILVER CELL
. 6.75 ± 0.05mm
. 4.60 ± 0.10mm
2.25± 0.1mm
2.6 ± 0.1mm
Cathode Cap
Separator
Anode Manganese
Anode Can
Gasket
Cathode Zinc Plaster
(A)100% silve(B)60% silver r
