Water Bottling Machine Xgf 18-18-6

XGF 18/18/6 Washing-Filling-Capping (Three-in-One) Unit made by our company is a new product which is researched and developed on the base of importing, assimilating and absorbing the advanced technology of the same kind of domestic and foreign products, combining several-year-production experience of the company. The unit collects washing, filling and capping together. It is driven by a transmission motor. It has advantages, such as high automation level, compact structure, beautiful appearance, convenient and simple operation, safe and reliable and adjustable continuous production capacity and others. It is an ideal no-gas liquid filling production equipment in the country. It is mainly suitable for filling and capping of round or square polyester bottles. According to the demands of different specifications of users, it is only changed a little in design to meet the user's demands.
Capacity Scale of Bottle: 350— 2000ml;
Diameter Scale of Bottle: φ 50mmφ 90mm;
Height Scale of Bottle: 150mm-310mm;
Drink Kind: Mineral Water, Pure Water, Fruit Juice, Wine and other no-gas liquid.

Main features
I. Rinser
1, The rotary wheel is a fully AISI304 stainless steel welded structure.
2, The machine applies unique overturning bottle clamp, which is an innovation of our company. This bottle clamp grips bottle at neck position, avoiding bottle mouth thread contamination caused by rubber gripper block of a traditional bottle clamp. Made of AISI304 stainless steel, this bottle clamp is hygienic and durable.
3, Covering of bottle clamps and elevator are product of IGUS
4, The rinse is driven by driving system positioned inside machine frame via gear transmission.
II. Filler
1, The filler is designed and manufactured with application of Italy technology, providing hardware guarantee for securing product quality and reducing loss.
2, Rotary wheel are fully made of stainless steel AISI304.
3, Filling valves are designed and manufactured with German technology, made of AISI316L, featuring high filling accuracy and high filling speed.
4, Bottles are raised and lowered by cam controlled lifting cylinder. Valve opening mechanism is actuated by air cylinder.
III. Capper
1) The capper is most precise part in 3 in 1 filling machine, because the quality of machine is important to running credibility and product quality.
2) The cover track has the device to prevent the reversal cover from passing and pick out the reversal cover. Meanwhile the photoelectric switch can stop the machine automatically when there is no cover on the track, by which it can avoid bottle without cover effectively.
